Draco Drum Magna Combi Unit
Draco Drum Magna Combi Unit
160mm (Height above water level gravity mode)
Flow rate – 50,000 LPH (gravity) @58µm
40,000 LPH (Pump fed) @58µm
Theoretical Pond Capacity – 8000 to 10000 Gallons (36,000 to 45,000 litres)
Inlets – 4 x 110mm
Outlets – 2 x 110mm plus 2” bio bypass connection
Bio capacity – Maximum 250 litres of media (Hel-x 13 recommended)
no media included
FEATURES
Sloped and slotted base to drum chamber, to eliminate bio media clogging and particle buildup in this area
Internal bio-bypass pipe for direct drum to shower connection. This is removable if not required
Large diameter and short length drum to maximise bio space and reduce water usage.
Extra deep waste tray with increased slope
Built in drum bypass plate
Hi-torque true brushless motor drive
All 12v dc operation at the drum
Plug and play design with single electrical connection
Modular component construction
Draco Drum Medius Combi unit
Draco Drum Medius Combi unit
The remotely sited controller has start / emergency stop buttons and a knob allowing you to change the length of wash. LED indicator shows the length of time between washes in minutes. It also has 2 leads – one to plug in to the mains supply (110v and 230v, auto selectable) and one to plug in to the drum. Status of the unit is via 4 colour coded LEDs. We didn’t think we could make it any simpler than that.
Low voltage, sealed water valves and drive units utilising an extremely low geared direct drive system mean that only 12 volts is anywhere near your pond water.
The Draco Drum Medius Combi unit was designed to run without a noisy and power hungry wash pump in most circumstances (they are available if required) . On standby the unit can use less than 1.2 watts and in full wash mode, use 35 watts. It is entirely possible to run it off a car battery for prolonged periods of time.
This model has been discontinued and replaced with Draco Drum C30/340 Combi Unit
https://youtu.be/8LNjERrfnY8
Draco drum solum 16
Draco drum solum 16 Features
- Dimensions – 610mm wide x 570mm long x 581mm depth
- Height above water level – 180mm
- Capacity – 3,700 Imp gallons per hour / 16,800 litres per hour (in gravity mode, pump fed less 25%)
- Pond Volume – Approx 7,500 UK gallons
- Twin 4” inlet and outlets
- Easily removable Bypass plates
The engineering and understanding of how filtration works was developed to produce Draco drum solum 16. As with the ‘Drop-in’ Draco drum range these have some unique features to help eliminate deadspots that are usually found in standalones.
The Draco drum solum 16 are pretty enough for you not to want to hide them away.
The remotely sited controller has start / emergency stop buttons and a knob allowing you to change the length of wash. LED indicator shows the length of time between washes in minutes. It also has 2 leads – one to plug in to the mains supply (110v and 230v, auto selectable) and one to plug in to the drum. Status of the unit is via 4 colour coded LEDs. We didn’t think we could make it any simpler than that.
Low voltage, sealed water valves and drive units utilising an extremely low geared direct drive system mean that only 12 volts is anywhere near your pond water.
The Draco drum solum 16 was designed to run without a noisy and power hungry wash pump in most circumstances (they are available if required) . On standby the unit can use less than 12 watts and in full wash mode, use 35 watts. It is entirely possible to run it off a car battery for prolonged periods of time.
This product has now been replaced by the S16
https://youtu.be/Tzi0gJNUnYg
Draco drum solum 25
Draco drum solum 25 Features
- Dimensions – 610mm wide x 700mm long x 581mm depth
- Height above water level – 180mm
- Capacity – 5,500 Imp. Gallons per hour / 25,000 litres per hour (in gravity mode, pump fed less 25%)
- Pond Volume – Approx 10,000 UK gallons
- Twin 4” inlet and outlets
- Easily removable Bypass plates
The engineering and understanding of how filtration works was developed to produce Draco drum solum 25. As with the ‘Drop-in’ Draco drum range these have some unique features to help eliminate deadspots that are usually found in standalones.
The Draco drum solum 25 are pretty enough for you not to want to hide them away.
The remotely sited controller has start / emergency stop buttons and a knob allowing you to change the length of wash. LED indicator shows the length of time between washes in minutes. It also has 2 leads – one to plug in to the mains supply (110v and 230v, auto selectable) and one to plug in to the drum. Status of the unit is via 4 colour coded LEDs. We didn’t think we could make it any simpler than that.
Low voltage, sealed water valves and drive units utilising an extremely low geared direct drive system mean that only 12 volts is anywhere near your pond water.
The Draco drum solum 25 was designed to run without a noisy and power hungry wash pump in most circumstances (they are available if required) . On standby the unit can use less than 12 watts and in full wash mode, use 35 watts. It is entirely possible to run it off a car battery for prolonged periods of time.
This product has been discontinued and replaced by the s30
https://youtu.be/NrBHjMBxV-A
Draco drum solum 70
Draco drum solum 70
- Dimensions – 738mm wide x 677mm long x 848mm depth
- Height above water level – 153mm
- Capacity – 15,400 Imp. Gallons per hour / 70,000 litres per hour (in gravity mode, pump fed less 25%)
- Pond Volume – Approx 16,000 UK gallons
- 4 X 4” inlets and 3 x 4″ outlets with an extra 2″ out for direct pump (other layouts can be specified)
- Drum mounted bypass plate
- Heavy duty 70 µm screen
- The remotely sited controller has start / emergency stop buttons and a knob allowing you to change the length of wash. LED indicator shows the length of time between washes in minutes. It also has 2 leads – one to plug in to the mains supply (110v and 230v, auto selectable) and one to plug in to the drum. Status of the unit is via 4 colour coded LEDs. We didn’t think we could make it any simpler than that.
- Low voltage, sealed water valves and drive units utilising an extremely low geared direct drive system mean that only 12 volts is anywhere near your pond water.
- Designed to run without a noisy and power hungry wash pump in most circumstances (they are available if required) . On standby the unit can use less than 12 watts and in full wash mode, use 35 watts.
This product has been discontinued and replaced by S100
Draco 2 Drum
Draco 2 Drum
The Draco 2 Drum is a reasonably priced and reliable unit. It comes with a choice of screens 77 microns and 58 microns depending on what is required. This Drum Can be used without a pressure wash pump – wash cycle runs off a normal garden hose with a minimum pressure of 2.5 bar with good flow. The Origin uses 28 watts of power while active, 11.5 watts while on standby and 78 watts while active with optional pressure pump. The Drive system comprises direct gearing to the back of the drum minimising complexity, the sealed motor unit is mounted on a single pivot swing arm as a safety feature to stop foreign bodies jamming the system. Its a fairly Simple installation via multiple types of adaptor plate which are interchangeable Single, pre-wired connection from controller to drum. Just plug and play ability to site controller up to 4 metres away from the unit. The Status of controller is available via simple, high intensity, colour coded LEDs and a digital minute between washes display. Easily accessible water level sensors that can be adjusted to accommodate any situation
All parts are modular and are replaceable in the event of any damage or failure Wholly designed and built in the UK by Draco Drum.
Technical Data:
- 2450gph / 13000lph flow rate
- Single 90mm inlet
- Filters to 58 micron
- Gravity or pump fed
- Designed to wash from mains pressure (down to 2 bar)
- 11 watts standby / 28 watts wash
- 12 volts DC waterside electrics
- Simple plug and play design
- Polypropolene / stainless steel construction
- Totally modular – all parts user replaceable
- Optional bolt on wash pump (for low water pressure areas)
This Product has been discontinued Please check out are other Draco drums
Origin 25 Draco Drum with twin inlets
Origin 25 Draco Drum with twin inlets
The Origin Draco Drum is a reasonably priced and reliable unit. It comes with a choice of screens 77 microns and 58 microns depending on what is required. This Drum Can be used without a pressure wash pump – wash cycle runs off a normal garden hose with a minimum pressure of 2.5 bar with good flow. The Origin uses 40 watts of power while active, 11.5 watts while on standby and 78 watts while active with optional pressure pump. The Drive system comprises direct gearing to the back of the drum minimising complexity, the sealed motor unit is mounted on a single pivot swing arm as a safety feature to stop foreign bodies jamming the system. Its a fairly Simple installation via multiple types of adaptor plate which are interchangeable Single, pre-wired connection from controller to drum. Just plug and play ability to site controller up to 4 metres away from the unit. The Status of controller is available via simple, high intensity, colour coded LEDs and a digital minute between washes display. Easily accessible water level sensors that can be adjusted to accommodate any situation
All parts are modular and are replaceable in the event of any damage or failure Wholly designed and built in the UK by Draco Drum.
Technical Data:
- 5500gph / 25000lph flow rate
- Twin 110mm inlets
- Filters to 58 micron
- Gravity or pump fed
- Designed to wash from mains pressure (down to 2 bar)
- 11 watts standby / 40 watts wash
- 12 volts DC waterside electrics
- Simple plug and play design
- Polypropylene / stainless steel construction
- Totally modular – all parts user replaceable
- Optional bolt on wash pump (for low water pressure areas)
