Heat pumps are an excellent way of heating koi ponds through the winter and summer months.

Using heat pumps as a pond heater will significantly reduce your pond heating costs compare with all other forms of pond heating.

Maintaining a reasonable pond temperature throughout the winter and spring (eg +12c) can have significant health benefits for the fish, helping to prevent disease and parasite attack

For use with koi ponds, it is important to select a heat pump that can operate down to low temperatures in order to maintain the required temperature of the pond throughout the winter and spring.

Typically a koi pond will be kept at between 10c and 15c throughout the winter and around 20- 22c in the summer.

Thermotec Eco Inverter
Thermotec Eco Inverter 12KW Heat Pump

Thermotec Eco Inverter 12KW Heat Pump



Thermotec Eco Inverter heat pumps are full inverter fan and compressor models offering high efficiency. They can work down to -5c air temperatures and have a 2-year warranty.

They are suitable for above ground and inground ponds .



New, the Thermotec Eco Inverter range of pool heat pumps offer an excellent inverter driven heat pump at a low cost with high value for money.

The Thermotec Eco Inverter range are fully inverter driven. This means that they automatically adjust the speed of the fan and compressor to precisely match the heat demand from the pool.

The ability to adjust the output of the heat pump allows the Thermotec Eco Inverter to deliver greatly reduced running costs with COPs of up to 12.5. This means that for every 1kw of electricity used by the heat pump, 12.5kw of heat is delivered to the pool. This delivers reduced running costs compared with other heat pumps on the market

In addition the inverter technology has a reduced electrical startup requirement, making them ideal for properties with a sensitive or limited electrical supply.



Thermotec Eco Inverter 12KW Heat Pump Features

  • Fully inverter driven with variable speed fan and compressor to deliver the lowest running costs with maximum heat output
  • High efficiency with COPs of up to 12.5. This means that for every 1kw of electricity used by the heat pump, up to 12.5kw of heat is returned to the pool.
  • Equipped with an easy to use touch screen display / control panel.
  • Top quality Mitsubishi variable speed inverter compressor
  • Brushless variable speed DC fan motor – very efficient with extremely quiet operation
  • Control panel is lockable to prevent tampering with the pool set temperature (useful for rented properties)
  • Five different models: 7kw, 9kw, 12kw, 16kw, 19kw
  • All models use single phase power (ie 220v to 240v)
  • Provides cooling and heating of pool water
  • Suitable for pools, swim spas, hot tubs and koi ponds etc
  • Soft start with reduced electrical startup requirements for properties with sensitive or limited power supplies
  • Low noise, variable speed fan.
  • Corrosion resistant case
  • Microprocessor controlled
  • Automatic hot gas defrosting.
  • Built in timer and clock
  • Set Temperatures for this model are 15-43 degrees
  • Silent mode
  • Titanium heat exchanger – resistant to corrosion from chlorine or salt pools.
  • Operates in air temperatures as low as -5 °C.
  • 2-Year Warranty
  • Note: these heat pumps do not come with a power cable or plug. They require a heavy duty piece of round flex cable with a 13A UK plug on the end.
  • The Eco 7kw, 9kw and 12kw can be run from a standard 13A UK Plug, larger models need to be hardwired as they can exceed 13A

What size heat pump do I require for my Pond ?

Model Kw Above Ground Pool

Max Pool Volume

In ground Pool
Max Pool Volume
In Ground
Absolute Max Pool Volume
Thermotec Eco Inverter Horizontal 7kw 18m3 25m3 35m3
Thermotec Eco Inverter Horizontal 9kw 25m3
30m3
50m3
Thermotec Eco Inverter Horizontal 12kw 35m3
40m3
60m3
Thermotec Eco Inverter Horizontal 16kw 45m3
50m3
75m3
Thermotec Eco Inverter Horizontal 19kw 55m3
70m3
95m3



COP And Performance

By using the latest inverter technology, the Thermotec Eco Inverter can out perform traditional on/off type heat pumps as well as many other inverter driven models.

Even as the outside air temperature falls, the Thermotec Eco Inverter will still perform well, delivering heat to your pool.

The Thermotec Inverter heat pumps can work well with outside air temperatures as low as -5c

The COP (Coefficient of Performance) is the ratio of the amount of heat (in kw) that the heat pump delivers to your pool compared to the electricity that the heat pump uses (in kw)

By using the latest inverter technology, the Thermotec Inverter has COPs up to 12.5. This means that in these conditions, 1kw of electricity consumed by the heat pump will output 12.5kw of heat to your pond!



Extremely Quiet Operation

The Thermotec Eco Inverter range work very silently thanks to a unique internal ventilation system and the inverter technology.

Both the fan and compressor automatically adjust their speed to match the pool heat demand, therefore once the pond is up to temperature, the unit can operate with reduced power consumption and noise.



Display

  • The current pool water temperature
  • The mode (e.g. heating or cooling)
  • Clock/time
  • If the timer function has been set
  • If the fan is operating
  • The current time and date
  • The outside ambient temperature
  • If there is a fault, a fault code is displayed to explain the problem
  • There is a protective flap over the display to protect it from the weather and UV rays from the sun
  • Inlet water temperature
  • Outlet water temperature

Electrical Requirements

Model Max Current Breaker Size Runs from 13A UK Plug? Min Cable Size mm2
7kw 6.4A 13A Yes 1.5mm2
9kw 8.4A 13A Yes 1.5mm2
12kw 10.9A 13A Yes 2.5mm2
16kw 16.5A 20A Type C No 4mm2
19kw 17.5A 20A Type C No 4mm2



The Thermotec Eco Inverter horizontal range of heat pumps come with:-

  • 2 x Water connection unions (with 50mm glue socket outlets – 1.5″ adaptor bushes available as an option)
  • 4 x Rubber mounting feet (heavy duty mounting blocks available as an option)

Warranty

The Thermotec Eco Inverter heat pumps come with a 2-year warranty on all components and 5-year warranty on the compressor and heat exchanger.

  • 2-year warranty on all components
  • 5-year warranty on the compressor and heat exchanger
  • UK: 1st year parts and labour warranty, Year 2 parts only warranty



not rated £1,825.00 inc. VAT Add to basket
Thermotec Eco Inverter
Thermotec Eco Inverter 16KW Heat Pump

Thermotec Eco Inverter 16KW Heat Pump



Thermotec Eco Inverter heat pumps are full inverter fan and compressor models offering high efficiency. They can work down to -5c air temperatures and have a 2-year warranty.

They are suitable for above ground and inground ponds .



New, the Thermotec Eco Inverter range of pool heat pumps offer an excellent inverter driven heat pump at a low cost with high value for money.

The Thermotec Eco Inverter range are fully inverter driven. This means that they automatically adjust the speed of the fan and compressor to precisely match the heat demand from the pool.

The ability to adjust the output of the heat pump allows the Thermotec Eco Inverter to deliver greatly reduced running costs with COPs of up to 12.5. This means that for every 1kw of electricity used by the heat pump, 12.5kw of heat is delivered to the pool. This delivers reduced running costs compared with other heat pumps on the market

In addition the inverter technology has a reduced electrical startup requirement, making them ideal for properties with a sensitive or limited electrical supply.



Thermotec Eco Inverter 16KW Heat Pump Features

  • Fully inverter driven with variable speed fan and compressor to deliver the lowest running costs with maximum heat output
  • High efficiency with COPs of up to 12.5. This means that for every 1kw of electricity used by the heat pump, up to 12.5kw of heat is returned to the pool.
  • Equipped with an easy to use touch screen display / control panel.
  • Top quality Mitsubishi variable speed inverter compressor
  • Brushless variable speed DC fan motor – very efficient with extremely quiet operation
  • Control panel is lockable to prevent tampering with the pool set temperature (useful for rented properties)
  • Five different models: 7kw, 9kw, 12kw, 16kw, 19kw
  • All models use single phase power (ie 220v to 240v)
  • Provides cooling and heating of pool water
  • Suitable for pools, swim spas, hot tubs and koi ponds etc
  • Soft start with reduced electrical startup requirements for properties with sensitive or limited power supplies
  • Low noise, variable speed fan.
  • Corrosion resistant case
  • Microprocessor controlled
  • Automatic hot gas defrosting.
  • Built in timer and clock
  • Set Temperatures for this model are 15-43 degrees
  • Silent mode
  • Titanium heat exchanger – resistant to corrosion from chlorine or salt pools.
  • Operates in air temperatures as low as -5 °C.
  • 2-Year Warranty
  • Note: these heat pumps do not come with a power cable or plug. They require a heavy duty piece of round flex cable with a 13A UK plug on the end.
  • The Eco 7kw, 9kw and 12kw can be run from a standard 13A UK Plug, larger models need to be hardwired as they can exceed 13A

What size heat pump do I require for my Pond ?

Model Kw Above Ground Pool

Max Pool Volume

In ground Pool
Max Pool Volume
In Ground
Absolute Max Pool Volume
Thermotec Eco Inverter Horizontal 7kw 18m3 25m3 35m3
Thermotec Eco Inverter Horizontal 9kw 25m3
30m3
50m3
Thermotec Eco Inverter Horizontal 12kw 35m3
40m3
60m3
Thermotec Eco Inverter Horizontal 16kw 45m3
50m3
75m3
Thermotec Eco Inverter Horizontal 19kw 55m3
70m3
95m3



COP And Performance

By using the latest inverter technology, the Thermotec Eco Inverter can out perform traditional on/off type heat pumps as well as many other inverter driven models.

Even as the outside air temperature falls, the Thermotec Eco Inverter will still perform well, delivering heat to your pool.

The Thermotec Inverter heat pumps can work well with outside air temperatures as low as -5c

The COP (Coefficient of Performance) is the ratio of the amount of heat (in kw) that the heat pump delivers to your pool compared to the electricity that the heat pump uses (in kw)

By using the latest inverter technology, the Thermotec Inverter has COPs up to 12.5. This means that in these conditions, 1kw of electricity consumed by the heat pump will output 12.5kw of heat to your pond!



Extremely Quiet Operation

The Thermotec Eco Inverter range work very silently thanks to a unique internal ventilation system and the inverter technology.

Both the fan and compressor automatically adjust their speed to match the pool heat demand, therefore once the pond is up to temperature, the unit can operate with reduced power consumption and noise.



Display

  • The current pool water temperature
  • The mode (e.g. heating or cooling)
  • Clock/time
  • If the timer function has been set
  • If the fan is operating
  • The current time and date
  • The outside ambient temperature
  • If there is a fault, a fault code is displayed to explain the problem
  • There is a protective flap over the display to protect it from the weather and UV rays from the sun
  • Inlet water temperature
  • Outlet water temperature

Electrical Requirements

Model Max Current Breaker Size Runs from 13A UK Plug? Min Cable Size mm2
7kw 6.4A 13A Yes 1.5mm2
9kw 8.4A 13A Yes 1.5mm2
12kw 10.9A 13A Yes 2.5mm2
16kw 16.5A 20A Type C No 4mm2
19kw 17.5A 20A Type C No 4mm2



The Thermotec Eco Inverter horizontal range of heat pumps come with:-

  • 2 x Water connection unions (with 50mm glue socket outlets – 1.5″ adaptor bushes available as an option)
  • 4 x Rubber mounting feet (heavy duty mounting blocks available as an option)

Warranty

The Thermotec Eco Inverter heat pumps come with a 2-year warranty on all components and 5-year warranty on the compressor and heat exchanger.

  • 2-year warranty on all components
  • 5-year warranty on the compressor and heat exchanger
  • UK: 1st year parts and labour warranty, Year 2 parts only warranty



not rated £2,175.00 inc. VAT Add to basket
Thermotec Eco Inverter
Thermotec Eco Inverter 19KW Heat Pump

Thermotec Eco Inverter 19KW Heat Pump



Thermotec Eco Inverter heat pumps are full inverter fan and compressor models offering high efficiency. They can work down to -5c air temperatures and have a 2-year warranty.

They are suitable for above ground and inground ponds .



New, the Thermotec Eco Inverter range of pool heat pumps offer an excellent inverter driven heat pump at a low cost with high value for money.

The Thermotec Eco Inverter range are fully inverter driven. This means that they automatically adjust the speed of the fan and compressor to precisely match the heat demand from the pool.

The ability to adjust the output of the heat pump allows the Thermotec Eco Inverter to deliver greatly reduced running costs with COPs of up to 12.5. This means that for every 1kw of electricity used by the heat pump, 12.5kw of heat is delivered to the pool. This delivers reduced running costs compared with other heat pumps on the market

In addition the inverter technology has a reduced electrical startup requirement, making them ideal for properties with a sensitive or limited electrical supply.



Thermotec Eco Inverter 19KW Heat Pump Features

  • Fully inverter driven with variable speed fan and compressor to deliver the lowest running costs with maximum heat output
  • High efficiency with COPs of up to 12.5. This means that for every 1kw of electricity used by the heat pump, up to 12.5kw of heat is returned to the pool.
  • Equipped with an easy to use touch screen display / control panel.
  • Top quality Mitsubishi variable speed inverter compressor
  • Brushless variable speed DC fan motor – very efficient with extremely quiet operation
  • Control panel is lockable to prevent tampering with the pool set temperature (useful for rented properties)
  • Five different models: 7kw, 9kw, 12kw, 16kw, 19kw
  • All models use single phase power (ie 220v to 240v)
  • Provides cooling and heating of pool water
  • Suitable for pools, swim spas, hot tubs and koi ponds etc
  • Soft start with reduced electrical startup requirements for properties with sensitive or limited power supplies
  • Low noise, variable speed fan.
  • Corrosion resistant case
  • Microprocessor controlled
  • Automatic hot gas defrosting.
  • Built in timer and clock
  • Set Temperatures for this model are 15-43 degrees
  • Silent mode
  • Titanium heat exchanger – resistant to corrosion from chlorine or salt pools.
  • Operates in air temperatures as low as -5 °C.
  • 2-Year Warranty
  • Note: these heat pumps do not come with a power cable or plug. They require a heavy duty piece of round flex cable with a 13A UK plug on the end.
  • The Eco 7kw, 9kw and 12kw can be run from a standard 13A UK Plug, larger models need to be hardwired as they can exceed 13A

What size heat pump do I require for my Pond ?

Model Kw Above Ground Pool

Max Pool Volume

In ground Pool
Max Pool Volume
In Ground
Absolute Max Pool Volume
Thermotec Eco Inverter Horizontal 7kw 18m3 25m3 35m3
Thermotec Eco Inverter Horizontal 9kw 25m3
30m3
50m3
Thermotec Eco Inverter Horizontal 12kw 35m3
40m3
60m3
Thermotec Eco Inverter Horizontal 16kw 45m3
50m3
75m3
Thermotec Eco Inverter Horizontal 19kw 55m3
70m3
95m3



COP And Performance

By using the latest inverter technology, the Thermotec Eco Inverter can out perform traditional on/off type heat pumps as well as many other inverter driven models.

Even as the outside air temperature falls, the Thermotec Eco Inverter will still perform well, delivering heat to your pool.

The Thermotec Inverter heat pumps can work well with outside air temperatures as low as -5c

The COP (Coefficient of Performance) is the ratio of the amount of heat (in kw) that the heat pump delivers to your pool compared to the electricity that the heat pump uses (in kw)

By using the latest inverter technology, the Thermotec Inverter has COPs up to 12.5. This means that in these conditions, 1kw of electricity consumed by the heat pump will output 12.5kw of heat to your pond!



Extremely Quiet Operation

The Thermotec Eco Inverter range work very silently thanks to a unique internal ventilation system and the inverter technology.

Both the fan and compressor automatically adjust their speed to match the pool heat demand, therefore once the pond is up to temperature, the unit can operate with reduced power consumption and noise.



Display

  • The current pool water temperature
  • The mode (e.g. heating or cooling)
  • Clock/time
  • If the timer function has been set
  • If the fan is operating
  • The current time and date
  • The outside ambient temperature
  • If there is a fault, a fault code is displayed to explain the problem
  • There is a protective flap over the display to protect it from the weather and UV rays from the sun
  • Inlet water temperature
  • Outlet water temperature

Electrical Requirements

Model Max Current Breaker Size Runs from 13A UK Plug? Min Cable Size mm2
7kw 6.4A 13A Yes 1.5mm2
9kw 8.4A 13A Yes 1.5mm2
12kw 10.9A 13A Yes 2.5mm2
16kw 16.5A 20A Type C No 4mm2
19kw 17.5A 20A Type C No 4mm2



The Thermotec Eco Inverter horizontal range of heat pumps come with:-

  • 2 x Water connection unions (with 50mm glue socket outlets – 1.5″ adaptor bushes available as an option)
  • 4 x Rubber mounting feet (heavy duty mounting blocks available as an option)

Warranty

The Thermotec Eco Inverter heat pumps come with a 2-year warranty on all components and 5-year warranty on the compressor and heat exchanger.

  • 2-year warranty on all components
  • 5-year warranty on the compressor and heat exchanger
  • UK: 1st year parts and labour warranty, Year 2 parts only warranty



not rated £2,625.00 inc. VAT Add to basket
Thermotec Eco Inverter
Thermotec Eco Inverter 7KW Heat Pump

Thermotec Eco Inverter 7KW Heat Pump



Thermotec Eco Inverter heat pumps are full inverter fan and compressor models offering high efficiency. They can work down to -5c air temperatures and have a 2-year warranty.

They are suitable for above ground and inground ponds .



New, the Thermotec Eco Inverter range of pool heat pumps offer an excellent inverter driven heat pump at a low cost with high value for money.

The Thermotec Eco Inverter range are fully inverter driven. This means that they automatically adjust the speed of the fan and compressor to precisely match the heat demand from the pool.

The ability to adjust the output of the heat pump allows the Thermotec Eco Inverter to deliver greatly reduced running costs with COPs of up to 12.5. This means that for every 1kw of electricity used by the heat pump, 12.5kw of heat is delivered to the pool. This delivers reduced running costs compared with other heat pumps on the market

In addition the inverter technology has a reduced electrical startup requirement, making them ideal for properties with a sensitive or limited electrical supply.



Thermotec Eco Inverter 7KW Heat Pump Features

  • Fully inverter driven with variable speed fan and compressor to deliver the lowest running costs with maximum heat output
  • High efficiency with COPs of up to 12.5. This means that for every 1kw of electricity used by the heat pump, up to 12.5kw of heat is returned to the pool.
  • Equipped with an easy to use touch screen display / control panel.
  • Top quality Mitsubishi variable speed inverter compressor
  • Brushless variable speed DC fan motor – very efficient with extremely quiet operation
  • Control panel is lockable to prevent tampering with the pool set temperature (useful for rented properties)
  • Five different models: 7kw, 9kw, 12kw, 16kw, 19kw
  • All models use single phase power (ie 220v to 240v)
  • Provides cooling and heating of pool water
  • Suitable for pools, swim spas, hot tubs and koi ponds etc
  • Soft start with reduced electrical startup requirements for properties with sensitive or limited power supplies
  • Low noise, variable speed fan.
  • Corrosion resistant case
  • Microprocessor controlled
  • Automatic hot gas defrosting.
  • Built in timer and clock
  • Set Temperatures for this model are 15-43 degrees
  • Silent mode
  • Titanium heat exchanger – resistant to corrosion from chlorine or salt pools.
  • Operates in air temperatures as low as -5 °C.
  • 2-Year Warranty
  • Note: these heat pumps do not come with a power cable or plug. They require a heavy duty piece of round flex cable with a 13A UK plug on the end.
  • The Eco 7kw, 9kw and 12kw can be run from a standard 13A UK Plug, larger models need to be hardwired as they can exceed 13A

What size heat pump do I require for my Pond ?

Model Kw Above Ground Pool

Max Pool Volume

In ground Pool
Max Pool Volume
In Ground
Absolute Max Pool Volume
Thermotec Eco Inverter Horizontal 7kw 18m3 25m3 35m3
Thermotec Eco Inverter Horizontal 9kw 25m3
30m3
50m3
Thermotec Eco Inverter Horizontal 12kw 35m3
40m3
60m3
Thermotec Eco Inverter Horizontal 16kw 45m3
50m3
75m3
Thermotec Eco Inverter Horizontal 19kw 55m3
70m3
95m3



COP And Performance

By using the latest inverter technology, the Thermotec Eco Inverter can out perform traditional on/off type heat pumps as well as many other inverter driven models.

Even as the outside air temperature falls, the Thermotec Eco Inverter will still perform well, delivering heat to your pool.

The Thermotec Inverter heat pumps can work well with outside air temperatures as low as -5c

The COP (Coefficient of Performance) is the ratio of the amount of heat (in kw) that the heat pump delivers to your pool compared to the electricity that the heat pump uses (in kw)

By using the latest inverter technology, the Thermotec Inverter has COPs up to 12.5. This means that in these conditions, 1kw of electricity consumed by the heat pump will output 12.5kw of heat to your pond!



Extremely Quiet Operation

The Thermotec Eco Inverter range work very silently thanks to a unique internal ventilation system and the inverter technology.

Both the fan and compressor automatically adjust their speed to match the pool heat demand, therefore once the pond is up to temperature, the unit can operate with reduced power consumption and noise.



Display

  • The current pool water temperature
  • The mode (e.g. heating or cooling)
  • Clock/time
  • If the timer function has been set
  • If the fan is operating
  • The current time and date
  • The outside ambient temperature
  • If there is a fault, a fault code is displayed to explain the problem
  • There is a protective flap over the display to protect it from the weather and UV rays from the sun
  • Inlet water temperature
  • Outlet water temperature

Electrical Requirements

Model Max Current Breaker Size Runs from 13A UK Plug? Min Cable Size mm2
7kw 6.4A 13A Yes 1.5mm2
9kw 8.4A 13A Yes 1.5mm2
12kw 10.9A 13A Yes 2.5mm2
16kw 16.5A 20A Type C No 4mm2
19kw 17.5A 20A Type C No 4mm2



The Thermotec Eco Inverter horizontal range of heat pumps come with:-

  • 2 x Water connection unions (with 50mm glue socket outlets – 1.5″ adaptor bushes available as an option)
  • 4 x Rubber mounting feet (heavy duty mounting blocks available as an option)

Warranty

The Thermotec Eco Inverter heat pumps come with a 2-year warranty on all components and 5-year warranty on the compressor and heat exchanger.

  • 2-year warranty on all components
  • 5-year warranty on the compressor and heat exchanger
  • UK: 1st year parts and labour warranty, Year 2 parts only warranty



not rated £1,550.00 inc. VAT Add to basket
Thermotec Eco Inverter
Thermotec Eco Inverter 9KW Heat Pump

Thermotec Eco Inverter 9KW Heat Pump



Thermotec Eco Inverter heat pumps are full inverter fan and compressor models offering high efficiency. They can work down to -5c air temperatures and have a 2-year warranty.

They are suitable for above ground and inground ponds .



New, the Thermotec Eco Inverter range of pool heat pumps offer an excellent inverter driven heat pump at a low cost with high value for money.

The Thermotec Eco Inverter range are fully inverter driven. This means that they automatically adjust the speed of the fan and compressor to precisely match the heat demand from the pool.

The ability to adjust the output of the heat pump allows the Thermotec Eco Inverter to deliver greatly reduced running costs with COPs of up to 12.5. This means that for every 1kw of electricity used by the heat pump, 12.5kw of heat is delivered to the pool. This delivers reduced running costs compared with other heat pumps on the market

In addition the inverter technology has a reduced electrical startup requirement, making them ideal for properties with a sensitive or limited electrical supply.



Thermotec Eco Inverter 9KW Heat Pump Features

  • Fully inverter driven with variable speed fan and compressor to deliver the lowest running costs with maximum heat output
  • High efficiency with COPs of up to 12.5. This means that for every 1kw of electricity used by the heat pump, up to 12.5kw of heat is returned to the pool.
  • Equipped with an easy to use touch screen display / control panel.
  • Top quality Mitsubishi variable speed inverter compressor
  • Brushless variable speed DC fan motor – very efficient with extremely quiet operation
  • Control panel is lockable to prevent tampering with the pool set temperature (useful for rented properties)
  • Five different models: 7kw, 9kw, 12kw, 16kw, 19kw
  • All models use single phase power (ie 220v to 240v)
  • Provides cooling and heating of pool water
  • Suitable for pools, swim spas, hot tubs and koi ponds etc
  • Soft start with reduced electrical startup requirements for properties with sensitive or limited power supplies
  • Low noise, variable speed fan.
  • Corrosion resistant case
  • Microprocessor controlled
  • Automatic hot gas defrosting.
  • Built in timer and clock
  • Set Temperatures for this model are 15-43 degrees
  • Silent mode
  • Titanium heat exchanger – resistant to corrosion from chlorine or salt pools.
  • Operates in air temperatures as low as -5 °C.
  • 2-Year Warranty
  • Note: these heat pumps do not come with a power cable or plug. They require a heavy duty piece of round flex cable with a 13A UK plug on the end.
  • The Eco 7kw, 9kw and 12kw can be run from a standard 13A UK Plug, larger models need to be hardwired as they can exceed 13A

What size heat pump do I require for my Pond ?

Model Kw Above Ground Pool

Max Pool Volume

In ground Pool
Max Pool Volume
In Ground
Absolute Max Pool Volume
Thermotec Eco Inverter Horizontal 7kw 18m3 25m3 35m3
Thermotec Eco Inverter Horizontal 9kw 25m3
30m3
50m3
Thermotec Eco Inverter Horizontal 12kw 35m3
40m3
60m3
Thermotec Eco Inverter Horizontal 16kw 45m3
50m3
75m3
Thermotec Eco Inverter Horizontal 19kw 55m3
70m3
95m3



COP And Performance

By using the latest inverter technology, the Thermotec Eco Inverter can out perform traditional on/off type heat pumps as well as many other inverter driven models.

Even as the outside air temperature falls, the Thermotec Eco Inverter will still perform well, delivering heat to your pool.

The Thermotec Inverter heat pumps can work well with outside air temperatures as low as -5c

The COP (Coefficient of Performance) is the ratio of the amount of heat (in kw) that the heat pump delivers to your pool compared to the electricity that the heat pump uses (in kw)

By using the latest inverter technology, the Thermotec Inverter has COPs up to 12.5. This means that in these conditions, 1kw of electricity consumed by the heat pump will output 12.5kw of heat to your pond!



Extremely Quiet Operation

The Thermotec Eco Inverter range work very silently thanks to a unique internal ventilation system and the inverter technology.

Both the fan and compressor automatically adjust their speed to match the pool heat demand, therefore once the pond is up to temperature, the unit can operate with reduced power consumption and noise.



Display

  • The current pool water temperature
  • The mode (e.g. heating or cooling)
  • Clock/time
  • If the timer function has been set
  • If the fan is operating
  • The current time and date
  • The outside ambient temperature
  • If there is a fault, a fault code is displayed to explain the problem
  • There is a protective flap over the display to protect it from the weather and UV rays from the sun
  • Inlet water temperature
  • Outlet water temperature

Electrical Requirements

Model Max Current Breaker Size Runs from 13A UK Plug? Min Cable Size mm2
7kw 6.4A 13A Yes 1.5mm2
9kw 8.4A 13A Yes 1.5mm2
12kw 10.9A 13A Yes 2.5mm2
16kw 16.5A 20A Type C No 4mm2
19kw 17.5A 20A Type C No 4mm2



The Thermotec Eco Inverter horizontal range of heat pumps come with:-

  • 2 x Water connection unions (with 50mm glue socket outlets – 1.5″ adaptor bushes available as an option)
  • 4 x Rubber mounting feet (heavy duty mounting blocks available as an option)

Warranty

The Thermotec Eco Inverter heat pumps come with a 2-year warranty on all components and 5-year warranty on the compressor and heat exchanger.

  • 2-year warranty on all components
  • 5-year warranty on the compressor and heat exchanger
  • UK: 1st year parts and labour warranty, Year 2 parts only warranty



not rated £1,695.00 inc. VAT Add to basket
Thermotec inverter Horizontal 12KW
Thermotec inverter Horizontal 12KW

Thermotec inverter Horizontal 12KW

New for 2018, the Thermotec Inverter range of pool heat pumps really do offer the best in terms of efficiency, performance, reliability and low noise operation.

The Thermotec Inverter range are fully inverter driven. This means that they automatically adjust the speed of the fan and compressor to precisely match the heat demand from the pool.

The ability to adjust the output of the heat pump allows the Thermotec inverter Horizontal 12KW to deliver greatly reduced running costs with COPs of up to 13. This means that for every 1kw of electricity used by the heat pump, 13kw of heat is delivered to the pool. This delivers reduced running costs compared with other heat pumps on the market

In addition the inverter technology has a reduced electrical startup requirement, making them ideal for properties with a sensitive or limited electrical supply.

Features
  • Fully inverter driven with variable speed fan and compressor to deliver the lowest running costs with maximum heat output
  • High efficiency with COPs of up to 13. This means that for every 1kw of electricity used by the heat pump, 13kw of heat is returned to the pool.
  • The desired water temperature can be adjusted in steps of 0.1  °C.
  • Equipped with an easy to use 5-inch colour touch screen display / control panel.
  • Remote control and monitor your heat pump via an app on your smartphone
  • Top quality Mitsubishi variable speed inverter compressor
  • Brushless variable speed DC fan motor – very efficient with extremely quiet operation
  • Control panel is lockable to prevent tampering with the pool set temperature (useful for rented properties)
  • Display shows temperature & power consumption curves to monitor the performance of the heat pump
  • Six different models:9kw, 12kw, 17kw, 19.5kw, 24.2kw, 28 kw and 34kw
  • All models single phase power (ie 220v to 240v)
  • Suitable for pools, swim spas, hot tubs and koi ponds etc
  • Desired water temperature can be set from +10c to +40c
  • Soft start with reduced electrical startup requirements for properties with sensitive or limited power supplies
  • Low noise, variable speed fan.
  • Corrosion resistant case
  • Microprocessor controlled
  • Automatic hot gas defrosting.
  • Suitable for use on koi ponds
  • Titanium heat exchanger – resistant to corrosion from chlorine or salt pools.
  • Operates in air temperatures as low as -15  °C.
  • Capable of heating and cooling, all year round.
  • Optional wifi module – control the heat pump from your smartphone or any web browser
  • 3-Year Warranty

The sizing guide for a covered pool is:-

Model Kw
Recommended Max Pool Volume
 Absolute Max Pool Volume
Thermotec Inverter Horizontal 9kw 9kw 30m3 45m3
Thermotec Inverter Horizontal 12kw 12kw
40m3
60m3
Thermotec Inverter Horizontal 17kw 17kw
50m3
75m3
Thermotec Inverter Horizontal 20kw 19.5kw
65m3
95m3
Thermotec Inverter Horizontal 24kw 24.2kw
75m3
120m3
Thermotec Inverter Vertical 29kw 28.6kw
93m3
116m3
Thermotec Inverter Vertical 34kw 34kw 109m3 136m3
Thermotec Inverter Vertical 34kw (3-phase) 34kw 109m3 136m3



For a koi pond that is heated all year round with a winter temperature of around 12c and a summer temperature of around 20-22c, we recommend the following sizing:-

 Pond Sizing Guide
Model
Max Pond Volume
Thermotec Inverter Horizontal 9kw 4500 gallons
Thermotec Inverter Horizontal 12kw 6000 gallons
Thermotec Inverter Horizontal 17kw
7500 gallons
Thermotec Inverter Horizontal 19.5kw
9600 gallons
Thermotec Inverter Horizontal 24kw
11,600 gallons
Thermotec Inverter Vertical 29kw
13,800 gallons
Thermotec Inverter Vertical 34kw
19,900 gallons
Thermotec Inverter Vertical 34kw (3 Phase) 19,900 gallons

(Note: This assumes that the pond is covered in winter and that a temperature of +12c is to be maintained over winter)

COP And Performance

By using the latest inverter technology, the Thermotec Inverter canout perform traditional on/off type heat pumps as well as many other inverter driven models.

Even as the outside air temperature falls, the Thermotec Inverter will still perform well, delivering heat to your pool.

The Thermotec Inverter heat pumps can work well with outside air temperatures as low as -15c

The COP (Coefficient of Performance) is the ratio of the amount of heat (in kw) that the heat pump delivers to your pool compared to the electricity that the heat pump uses (in kw)

By using the latest inverter technology, the Thermotec Inverter has COPs up to 13.6. This means that in these conditions, 1kw of electricity consumed by the heat pump will output 13.6kw of heat to your pool !

Extremely Quiet Operation

The Thermotec Inverter range work very silently thanks to a unique internal ventilation system and the inverter technology.

Both the fan and compressor automatically adjust their speed to match the pool heat demand, therefore once the pool is up to temperature, the unit can operate with reduced power consumption and noise.

Colour Touch Screen Controls

The Thermotec Inverter have a unique 5″ colour backlit touch screen control/display panel

This provides easy to use controls

The display will show:-

  • The current pool water temperature
  • The mode (eg heating or cooling)
  • If the timer function has been set
  • If the fan is operating
  • The current time and date
  • The outside ambient temperature
  • If there is a fault, a fault code is displayed to explain the problem

In addition, the display can show:-

  • A graph of the temperature of the pool over time so that you can see how the pool temperature is being maintained by the Thermotec Inverter heat pump
  • A graph of the power consumed by the heat pump over time

The colour display is backlit making it easy to read in low light conditions and also in bright sunlight

Wi-Fi Control

The optional Wi-Fi module allows the Thermotec inverter Horizontal 12KW to be monitored and controlled from a smartphone or any internet web browser.

The Thermotec inverter Horizontal 12KW App is available for both Android and iPhone

The Wi-Fi module simply connects to the heat pump via the supplied cable

The module is then joined to your wi-fi network to allow it to communicate with the internet

The wifi module also allows HeatPumps4Pools to provide remote monitoring and support of your heat pump with the ability to change any settings if required. This greatly enhances the speed and efficiency of our technical support.

The Thermotec inverter Horizontal 12KW app can then be installed into your smart phone to give full remote control and monitoring of your pool heat pump.

Note: A a wifi signal is required at the location of the heat pump in order for the wifi module to be able to connect to your wifi.

Please test the strength of the wifi signal eg with a laptop or your smart phone before purchasing the wifi module.

If you do not have a wifi signal at the heat pump’s location, then you can either:-

  1. Use a wifi signal extender to boost the signal in the area of the heat pump
  2. Use power lan adaptors plugged into mains sockets in the house and the pool shed. You can then connect a wifi extended to the powerlan adaptor in your pool shed.

Using the app you can:-

  • Turn the heat pump on and off
  • See the current pool water temperature
  • Alter the desired pool set temperature
  • Set the timer
  • View the pool temperature history graph
  • Change the mode of the heat pump from heating, cooling and auto modes
  • Put the heat pump in and out of silence mode (eg for nightime use)
  • Show the weather temperatures and information
  • Display any error codes and messages

The Thermotec inverter Horizontal 12KW heat pump comes with:-

  • 2 x Water connection unions
  • 1 x Basic Winter cover
  • 4 x Rubber mounting feet



not rated £2,245.00 inc. VAT Add to basket
Thermotec inverter Horizontal 17KW
Thermotec inverter Horizontal 17KW

Thermotec inverter Horizontal 17KW

New for 2018, the Thermotec Inverter range of pool heat pumps really do offer the best in terms of efficiency, performance, reliability and low noise operation.

The Thermotec Inverter range are fully inverter driven. This means that they automatically adjust the speed of the fan and compressor to precisely match the heat demand from the pool.

The ability to adjust the output of the heat pump allows the Thermotec inverter Horizontal 17KW to deliver greatly reduced running costs with COPs of up to 13. This means that for every 1kw of electricity used by the heat pump, 13kw of heat is delivered to the pool. This delivers reduced running costs compared with other heat pumps on the market

In addition the inverter technology has a reduced electrical startup requirement, making them ideal for properties with a sensitive or limited electrical supply.

Features
  • Fully inverter driven with variable speed fan and compressor to deliver the lowest running costs with maximum heat output
  • High efficiency with COPs of up to 13. This means that for every 1kw of electricity used by the heat pump, 13kw of heat is returned to the pool.
  • The desired water temperature can be adjusted in steps of 0.1  °C.
  • Equipped with an easy to use 5-inch colour touch screen display / control panel.
  • Remote control and monitor your heat pump via an app on your smartphone
  • Top quality Mitsubishi variable speed inverter compressor
  • Brushless variable speed DC fan motor – very efficient with extremely quiet operation
  • Control panel is lockable to prevent tampering with the pool set temperature (useful for rented properties)
  • Display shows temperature & power consumption curves to monitor the performance of the heat pump
  • Six different models:9kw, 12kw, 17kw, 19.5kw, 24.2kw, 28 kw and 34kw
  • All models single phase power (ie 220v to 240v)
  • Suitable for pools, swim spas, hot tubs and koi ponds etc
  • Desired water temperature can be set from +10c to +40c
  • Soft start with reduced electrical startup requirements for properties with sensitive or limited power supplies
  • Low noise, variable speed fan.
  • Corrosion resistant case
  • Microprocessor controlled
  • Automatic hot gas defrosting.
  • Suitable for use on koi ponds
  • Titanium heat exchanger – resistant to corrosion from chlorine or salt pools.
  • Operates in air temperatures as low as -15  °C.
  • Capable of heating and cooling, all year round.
  • Optional wifi module – control the heat pump from your smartphone or any web browser
  • 3-Year Warranty

The sizing guide for a covered pool is:-

Model Kw
Recommended Max Pool Volume
 Absolute Max Pool Volume
Thermotec Inverter Horizontal 9kw 9kw 30m3 45m3
Thermotec Inverter Horizontal 12kw 12kw
40m3
60m3
Thermotec Inverter Horizontal 17kw 17kw
50m3
75m3
Thermotec Inverter Horizontal 20kw 19.5kw
65m3
95m3
Thermotec Inverter Horizontal 24kw 24.2kw
75m3
120m3
Thermotec Inverter Vertical 29kw 28.6kw
93m3
116m3
Thermotec Inverter Vertical 34kw 34kw 109m3 136m3
Thermotec Inverter Vertical 34kw (3-phase) 34kw 109m3 136m3



For a koi pond that is heated all year round with a winter temperature of around 12c and a summer temperature of around 20-22c, we recommend the following sizing:-

 Pond Sizing Guide
Model
Max Pond Volume
Thermotec Inverter Horizontal 9kw 4500 gallons
Thermotec Inverter Horizontal 12kw 6000 gallons
Thermotec Inverter Horizontal 17kw
7500 gallons
Thermotec Inverter Horizontal 19.5kw
9600 gallons
Thermotec Inverter Horizontal 24kw
11,600 gallons
Thermotec Inverter Vertical 29kw
13,800 gallons
Thermotec Inverter Vertical 34kw
19,900 gallons
Thermotec Inverter Vertical 34kw (3 Phase) 19,900 gallons

(Note: This assumes that the pond is covered in winter and that a temperature of +12c is to be maintained over winter)

COP And Performance

By using the latest inverter technology, the Thermotec Inverter canout perform traditional on/off type heat pumps as well as many other inverter driven models.

Even as the outside air temperature falls, the Thermotec Inverter will still perform well, delivering heat to your pool.

The Thermotec Inverter heat pumps can work well with outside air temperatures as low as -15c

The COP (Coefficient of Performance) is the ratio of the amount of heat (in kw) that the heat pump delivers to your pool compared to the electricity that the heat pump uses (in kw)

By using the latest inverter technology, the Thermotec Inverter has COPs up to 13.6. This means that in these conditions, 1kw of electricity consumed by the heat pump will output 13.6kw of heat to your pool !

Extremely Quiet Operation

The Thermotec Inverter range work very silently thanks to a unique internal ventilation system and the inverter technology.

Both the fan and compressor automatically adjust their speed to match the pool heat demand, therefore once the pool is up to temperature, the unit can operate with reduced power consumption and noise.

Colour Touch Screen Controls

The Thermotec Inverter have a unique 5″ colour backlit touch screen control/display panel

This provides easy to use controls

The display will show:-

  • The current pool water temperature
  • The mode (eg heating or cooling)
  • If the timer function has been set
  • If the fan is operating
  • The current time and date
  • The outside ambient temperature
  • If there is a fault, a fault code is displayed to explain the problem

In addition, the display can show:-

  • A graph of the temperature of the pool over time so that you can see how the pool temperature is being maintained by the Thermotec Inverter heat pump
  • A graph of the power consumed by the heat pump over time

The colour display is backlit making it easy to read in low light conditions and also in bright sunlight

Wi-Fi Control

The optional Wi-Fi module allows the Thermotec inverter Horizontal 12KW to be monitored and controlled from a smartphone or any internet web browser.

The Thermotec inverter Horizontal 17KW App is available for both Android and iPhone

The Wi-Fi module simply connects to the heat pump via the supplied cable

The module is then joined to your wi-fi network to allow it to communicate with the internet

The wifi module also allows HeatPumps4Pools to provide remote monitoring and support of your heat pump with the ability to change any settings if required. This greatly enhances the speed and efficiency of our technical support.

The Thermotec inverter Horizontal 17KW app can then be installed into your smart phone to give full remote control and monitoring of your pool heat pump.

Note: A a wifi signal is required at the location of the heat pump in order for the wifi module to be able to connect to your wifi.

Please test the strength of the wifi signal eg with a laptop or your smart phone before purchasing the wifi module.

If you do not have a wifi signal at the heat pump’s location, then you can either:-

  1. Use a wifi signal extender to boost the signal in the area of the heat pump
  2. Use power lan adaptors plugged into mains sockets in the house and the pool shed. You can then connect a wifi extended to the powerlan adaptor in your pool shed.

Using the app you can:-

  • Turn the heat pump on and off
  • See the current pool water temperature
  • Alter the desired pool set temperature
  • Set the timer
  • View the pool temperature history graph
  • Change the mode of the heat pump from heating, cooling and auto modes
  • Put the heat pump in and out of silence mode (eg for nightime use)
  • Show the weather temperatures and information
  • Display any error codes and messages

The Thermotec inverter Horizontal 17KW heat pump comes with:-

  • 2 x Water connection unions
  • 1 x Basic Winter cover
  • 4 x Rubber mounting feet



not rated £3,165.00 inc. VAT Add to basket
Thermotec inverter Horizontal 20KW
Thermotec inverter Horizontal 20KW

Thermotec inverter Horizontal 20KW

New for 2018, the Thermotec Inverter range of pool heat pumps really do offer the best in terms of efficiency, performance, reliability and low noise operation.

The Thermotec Inverter range are fully inverter driven. This means that they automatically adjust the speed of the fan and compressor to precisely match the heat demand from the pool.

The ability to adjust the output of the heat pump allows the Thermotec inverter Horizontal 20KW to deliver greatly reduced running costs with COPs of up to 13. This means that for every 1kw of electricity used by the heat pump, 13kw of heat is delivered to the pool. This delivers reduced running costs compared with other heat pumps on the market

In addition the inverter technology has a reduced electrical startup requirement, making them ideal for properties with a sensitive or limited electrical supply.

Features
  • Fully inverter driven with variable speed fan and compressor to deliver the lowest running costs with maximum heat output
  • High efficiency with COPs of up to 13. This means that for every 1kw of electricity used by the heat pump, 13kw of heat is returned to the pool.
  • The desired water temperature can be adjusted in steps of 0.1  °C.
  • Equipped with an easy to use 5-inch colour touch screen display / control panel.
  • Remote control and monitor your heat pump via an app on your smartphone
  • Top quality Mitsubishi variable speed inverter compressor
  • Brushless variable speed DC fan motor – very efficient with extremely quiet operation
  • Control panel is lockable to prevent tampering with the pool set temperature (useful for rented properties)
  • Display shows temperature & power consumption curves to monitor the performance of the heat pump
  • Six different models:9kw, 12kw, 17kw, 19.5kw, 24.2kw, 28 kw and 34kw
  • All models single phase power (ie 220v to 240v)
  • Suitable for pools, swim spas, hot tubs and koi ponds etc
  • Desired water temperature can be set from +10c to +40c
  • Soft start with reduced electrical startup requirements for properties with sensitive or limited power supplies
  • Low noise, variable speed fan.
  • Corrosion resistant case
  • Microprocessor controlled
  • Automatic hot gas defrosting.
  • Suitable for use on koi ponds
  • Titanium heat exchanger – resistant to corrosion from chlorine or salt pools.
  • Operates in air temperatures as low as -15  °C.
  • Capable of heating and cooling, all year round.
  • Optional wifi module – control the heat pump from your smartphone or any web browser
  • 3-Year Warranty

The sizing guide for a covered pool is:-

Model Kw
Recommended Max Pool Volume
 Absolute Max Pool Volume
Thermotec Inverter Horizontal 9kw 9kw 30m3 45m3
Thermotec Inverter Horizontal 12kw 12kw
40m3
60m3
Thermotec Inverter Horizontal 17kw 17kw
50m3
75m3
Thermotec Inverter Horizontal 20kw 19.5kw
65m3
95m3
Thermotec Inverter Horizontal 24kw 24.2kw
75m3
120m3
Thermotec Inverter Vertical 29kw 28.6kw
93m3
116m3
Thermotec Inverter Vertical 34kw 34kw 109m3 136m3
Thermotec Inverter Vertical 34kw (3-phase) 34kw 109m3 136m3



For a koi pond that is heated all year round with a winter temperature of around 12c and a summer temperature of around 20-22c, we recommend the following sizing:-

 Pond Sizing Guide
Model
Max Pond Volume
Thermotec Inverter Horizontal 9kw 4500 gallons
Thermotec Inverter Horizontal 12kw 6000 gallons
Thermotec Inverter Horizontal 17kw
7500 gallons
Thermotec Inverter Horizontal 19.5kw
9600 gallons
Thermotec Inverter Horizontal 24kw
11,600 gallons
Thermotec Inverter Vertical 29kw
13,800 gallons
Thermotec Inverter Vertical 34kw
19,900 gallons
Thermotec Inverter Vertical 34kw (3 Phase) 19,900 gallons

(Note: This assumes that the pond is covered in winter and that a temperature of +12c is to be maintained over winter)

COP And Performance

By using the latest inverter technology, the Thermotec Inverter canout perform traditional on/off type heat pumps as well as many other inverter driven models.

Even as the outside air temperature falls, the Thermotec Inverter will still perform well, delivering heat to your pool.

The Thermotec Inverter heat pumps can work well with outside air temperatures as low as -15c

The COP (Coefficient of Performance) is the ratio of the amount of heat (in kw) that the heat pump delivers to your pool compared to the electricity that the heat pump uses (in kw)

By using the latest inverter technology, the Thermotec Inverter has COPs up to 13.6. This means that in these conditions, 1kw of electricity consumed by the heat pump will output 13.6kw of heat to your pool !

Extremely Quiet Operation

The Thermotec Inverter range work very silently thanks to a unique internal ventilation system and the inverter technology.

Both the fan and compressor automatically adjust their speed to match the pool heat demand, therefore once the pool is up to temperature, the unit can operate with reduced power consumption and noise.

Colour Touch Screen Controls

The Thermotec Inverter have a unique 5″ colour backlit touch screen control/display panel

This provides easy to use controls

The display will show:-

  • The current pool water temperature
  • The mode (eg heating or cooling)
  • If the timer function has been set
  • If the fan is operating
  • The current time and date
  • The outside ambient temperature
  • If there is a fault, a fault code is displayed to explain the problem

In addition, the display can show:-

  • A graph of the temperature of the pool over time so that you can see how the pool temperature is being maintained by the Thermotec Inverter heat pump
  • A graph of the power consumed by the heat pump over time

The colour display is backlit making it easy to read in low light conditions and also in bright sunlight

Wi-Fi Control

The optional Wi-Fi module allows the Thermotec inverter Horizontal 20KW to be monitored and controlled from a smartphone or any internet web browser.

The Thermotec inverter Horizontal 12KW App is available for both Android and iPhone

The Wi-Fi module simply connects to the heat pump via the supplied cable

The module is then joined to your wi-fi network to allow it to communicate with the internet

The wifi module also allows HeatPumps4Pools to provide remote monitoring and support of your heat pump with the ability to change any settings if required. This greatly enhances the speed and efficiency of our technical support.

The Thermotec inverter Horizontal 20KW app can then be installed into your smart phone to give full remote control and monitoring of your pool heat pump.

Note: A a wifi signal is required at the location of the heat pump in order for the wifi module to be able to connect to your wifi.

Please test the strength of the wifi signal eg with a laptop or your smart phone before purchasing the wifi module.

If you do not have a wifi signal at the heat pump’s location, then you can either:-

  1. Use a wifi signal extender to boost the signal in the area of the heat pump
  2. Use power lan adaptors plugged into mains sockets in the house and the pool shed. You can then connect a wifi extended to the powerlan adaptor in your pool shed.

Using the app you can:-

  • Turn the heat pump on and off
  • See the current pool water temperature
  • Alter the desired pool set temperature
  • Set the timer
  • View the pool temperature history graph
  • Change the mode of the heat pump from heating, cooling and auto modes
  • Put the heat pump in and out of silence mode (eg for nightime use)
  • Show the weather temperatures and information
  • Display any error codes and messages

The Thermotec inverter Horizontal 20KW heat pump comes with:-

  • 2 x Water connection unions
  • 1 x Basic Winter cover
  • 4 x Rubber mounting feet



not rated £3,525.00 inc. VAT Add to basket
Thermotec inverter Horizontal 24KW
Thermotec inverter Horizontal 24KW

Thermotec inverter Horizontal 24KW

New for 2018, the Thermotec Inverter range of pool heat pumps really do offer the best in terms of efficiency, performance, reliability and low noise operation.

The Thermotec Inverter range are fully inverter driven. This means that they automatically adjust the speed of the fan and compressor to precisely match the heat demand from the pool.

The ability to adjust the output of the heat pump allows the Thermotec inverter Horizontal 24KW to deliver greatly reduced running costs with COPs of up to 13. This means that for every 1kw of electricity used by the heat pump, 13kw of heat is delivered to the pool. This delivers reduced running costs compared with other heat pumps on the market

In addition the inverter technology has a reduced electrical startup requirement, making them ideal for properties with a sensitive or limited electrical supply.

Features
  • Fully inverter driven with variable speed fan and compressor to deliver the lowest running costs with maximum heat output
  • High efficiency with COPs of up to 13. This means that for every 1kw of electricity used by the heat pump, 13kw of heat is returned to the pool.
  • The desired water temperature can be adjusted in steps of 0.1  °C.
  • Equipped with an easy to use 5-inch colour touch screen display / control panel.
  • Remote control and monitor your heat pump via an app on your smartphone
  • Top quality Mitsubishi variable speed inverter compressor
  • Brushless variable speed DC fan motor – very efficient with extremely quiet operation
  • Control panel is lockable to prevent tampering with the pool set temperature (useful for rented properties)
  • Display shows temperature & power consumption curves to monitor the performance of the heat pump
  • Six different models:9kw, 12kw, 17kw, 19.5kw, 24.2kw, 28 kw and 34kw
  • All models single phase power (ie 220v to 240v)
  • Suitable for pools, swim spas, hot tubs and koi ponds etc
  • Desired water temperature can be set from +10c to +40c
  • Soft start with reduced electrical startup requirements for properties with sensitive or limited power supplies
  • Low noise, variable speed fan.
  • Corrosion resistant case
  • Microprocessor controlled
  • Automatic hot gas defrosting.
  • Suitable for use on koi ponds
  • Titanium heat exchanger – resistant to corrosion from chlorine or salt pools.
  • Operates in air temperatures as low as -15  °C.
  • Capable of heating and cooling, all year round.
  • Optional wifi module – control the heat pump from your smartphone or any web browser
  • 3-Year Warranty

The sizing guide for a covered pool is:-

Model Kw
Recommended Max Pool Volume
 Absolute Max Pool Volume
Thermotec Inverter Horizontal 9kw 9kw 30m3 45m3
Thermotec Inverter Horizontal 12kw 12kw
40m3
60m3
Thermotec Inverter Horizontal 17kw 17kw
50m3
75m3
Thermotec Inverter Horizontal 20kw 19.5kw
65m3
95m3
Thermotec Inverter Horizontal 24kw 24.2kw
75m3
120m3
Thermotec Inverter Vertical 29kw 28.6kw
93m3
116m3
Thermotec Inverter Vertical 34kw 34kw 109m3 136m3
Thermotec Inverter Vertical 34kw (3-phase) 34kw 109m3 136m3



For a koi pond that is heated all year round with a winter temperature of around 12c and a summer temperature of around 20-22c, we recommend the following sizing:-

 Pond Sizing Guide
Model
Max Pond Volume
Thermotec Inverter Horizontal 9kw 4500 gallons
Thermotec Inverter Horizontal 12kw 6000 gallons
Thermotec Inverter Horizontal 17kw
7500 gallons
Thermotec Inverter Horizontal 19.5kw
9600 gallons
Thermotec Inverter Horizontal 24kw
11,600 gallons
Thermotec Inverter Vertical 29kw
13,800 gallons
Thermotec Inverter Vertical 34kw
19,900 gallons
Thermotec Inverter Vertical 34kw (3 Phase) 19,900 gallons

(Note: This assumes that the pond is covered in winter and that a temperature of +12c is to be maintained over winter)

COP And Performance

By using the latest inverter technology, the Thermotec Inverter canout perform traditional on/off type heat pumps as well as many other inverter driven models.

Even as the outside air temperature falls, the Thermotec Inverter will still perform well, delivering heat to your pool.

The Thermotec Inverter heat pumps can work well with outside air temperatures as low as -15c

The COP (Coefficient of Performance) is the ratio of the amount of heat (in kw) that the heat pump delivers to your pool compared to the electricity that the heat pump uses (in kw)

By using the latest inverter technology, the Thermotec Inverter has COPs up to 13.6. This means that in these conditions, 1kw of electricity consumed by the heat pump will output 13.6kw of heat to your pool !

Extremely Quiet Operation

The Thermotec Inverter range work very silently thanks to a unique internal ventilation system and the inverter technology.

Both the fan and compressor automatically adjust their speed to match the pool heat demand, therefore once the pool is up to temperature, the unit can operate with reduced power consumption and noise.

Colour Touch Screen Controls

The Thermotec Inverter have a unique 5″ colour backlit touch screen control/display panel

This provides easy to use controls

The display will show:-

  • The current pool water temperature
  • The mode (eg heating or cooling)
  • If the timer function has been set
  • If the fan is operating
  • The current time and date
  • The outside ambient temperature
  • If there is a fault, a fault code is displayed to explain the problem

In addition, the display can show:-

  • A graph of the temperature of the pool over time so that you can see how the pool temperature is being maintained by the Thermotec Inverter heat pump
  • A graph of the power consumed by the heat pump over time

The colour display is backlit making it easy to read in low light conditions and also in bright sunlight

Wi-Fi Control

The optional Wi-Fi module allows the Thermotec inverter Horizontal 24KW to be monitored and controlled from a smartphone or any internet web browser.

The Thermotec inverter Horizontal 24KW App is available for both Android and iPhone

The Wi-Fi module simply connects to the heat pump via the supplied cable

The module is then joined to your wi-fi network to allow it to communicate with the internet

The wifi module also allows HeatPumps4Pools to provide remote monitoring and support of your heat pump with the ability to change any settings if required. This greatly enhances the speed and efficiency of our technical support.

The Thermotec inverter Horizontal 24KW app can then be installed into your smart phone to give full remote control and monitoring of your pool heat pump.

Note: A a wifi signal is required at the location of the heat pump in order for the wifi module to be able to connect to your wifi.

Please test the strength of the wifi signal eg with a laptop or your smart phone before purchasing the wifi module.

If you do not have a wifi signal at the heat pump’s location, then you can either:-

  1. Use a wifi signal extender to boost the signal in the area of the heat pump
  2. Use power lan adaptors plugged into mains sockets in the house and the pool shed. You can then connect a wifi extended to the powerlan adaptor in your pool shed.

Using the app you can:-

  • Turn the heat pump on and off
  • See the current pool water temperature
  • Alter the desired pool set temperature
  • Set the timer
  • View the pool temperature history graph
  • Change the mode of the heat pump from heating, cooling and auto modes
  • Put the heat pump in and out of silence mode (eg for nightime use)
  • Show the weather temperatures and information
  • Display any error codes and messages

The Thermotec inverter Horizontal 24KW heat pump comes with:-

  • 2 x Water connection unions
  • 1 x Basic Winter cover
  • 4 x Rubber mounting feet



not rated £3,850.00 inc. VAT Add to basket
Thermotec inverter Horizontal 9KW
Thermotec inverter Horizontal 9KW

Thermotec inverter Horizontal 9KW

New for 2018, the Thermotec Inverter range of pool heat pumps really do offer the best in terms of efficiency, performance, reliability and low noise operation.

The Thermotec Inverter range are fully inverter driven. This means that they automatically adjust the speed of the fan and compressor to precisely match the heat demand from the pool.

The ability to adjust the output of the heat pump allows the Thermotec inverter Horizontal 9KW to deliver greatly reduced running costs with COPs of up to 13. This means that for every 1kw of electricity used by the heat pump, 13kw of heat is delivered to the pool. This delivers reduced running costs compared with other heat pumps on the market

In addition the inverter technology has a reduced electrical startup requirement, making them ideal for properties with a sensitive or limited electrical supply.

Features
  • Fully inverter driven with variable speed fan and compressor to deliver the lowest running costs with maximum heat output
  • High efficiency with COPs of up to 13. This means that for every 1kw of electricity used by the heat pump, 13kw of heat is returned to the pool.
  • The desired water temperature can be adjusted in steps of 0.1  °C.
  • Equipped with an easy to use 5-inch colour touch screen display / control panel.
  • Remote control and monitor your heat pump via an app on your smartphone
  • Top quality Mitsubishi variable speed inverter compressor
  • Brushless variable speed DC fan motor – very efficient with extremely quiet operation
  • Control panel is lockable to prevent tampering with the pool set temperature (useful for rented properties)
  • Display shows temperature & power consumption curves to monitor the performance of the heat pump
  • Six different models:9kw, 12kw, 17kw, 19.5kw, 24.2kw, 28 kw and 34kw
  • All models single phase power (ie 220v to 240v)
  • Suitable for pools, swim spas, hot tubs and koi ponds etc
  • Desired water temperature can be set from +10c to +40c
  • Soft start with reduced electrical startup requirements for properties with sensitive or limited power supplies
  • Low noise, variable speed fan.
  • Corrosion resistant case
  • Microprocessor controlled
  • Automatic hot gas defrosting.
  • Suitable for use on koi ponds
  • Titanium heat exchanger – resistant to corrosion from chlorine or salt pools.
  • Operates in air temperatures as low as -15  °C.
  • Capable of heating and cooling, all year round.
  • Optional wifi module – control the heat pump from your smartphone or any web browser
  • 3-Year Warranty

The sizing guide for a covered pool is:-

Model Kw
Recommended Max Pool Volume
 Absolute Max Pool Volume
Thermotec Inverter Horizontal 9kw 9kw 30m3 45m3
Thermotec Inverter Horizontal 12kw 12kw
40m3
60m3
Thermotec Inverter Horizontal 17kw 17kw
50m3
75m3
Thermotec Inverter Horizontal 20kw 19.5kw
65m3
95m3
Thermotec Inverter Horizontal 24kw 24.2kw
75m3
120m3
Thermotec Inverter Vertical 29kw 28.6kw
93m3
116m3
Thermotec Inverter Vertical 34kw 34kw 109m3 136m3
Thermotec Inverter Vertical 34kw (3-phase) 34kw 109m3 136m3



For a koi pond that is heated all year round with a winter temperature of around 12c and a summer temperature of around 20-22c, we recommend the following sizing:-

 Pond Sizing Guide
Model
Max Pond Volume
Thermotec Inverter Horizontal 9kw 4500 gallons
Thermotec Inverter Horizontal 12kw 6000 gallons
Thermotec Inverter Horizontal 17kw
7500 gallons
Thermotec Inverter Horizontal 19.5kw
9600 gallons
Thermotec Inverter Horizontal 24kw
11,600 gallons
Thermotec Inverter Vertical 29kw
13,800 gallons
Thermotec Inverter Vertical 34kw
19,900 gallons
Thermotec Inverter Vertical 34kw (3 Phase) 19,900 gallons

(Note: This assumes that the pond is covered in winter and that a temperature of +12c is to be maintained over winter)

COP And Performance

By using the latest inverter technology, the Thermotec Inverter canout perform traditional on/off type heat pumps as well as many other inverter driven models.

Even as the outside air temperature falls, the Thermotec Inverter will still perform well, delivering heat to your pool.

The Thermotec Inverter heat pumps can work well with outside air temperatures as low as -15c

The COP (Coefficient of Performance) is the ratio of the amount of heat (in kw) that the heat pump delivers to your pool compared to the electricity that the heat pump uses (in kw)

By using the latest inverter technology, the Thermotec Inverter has COPs up to 13.6. This means that in these conditions, 1kw of electricity consumed by the heat pump will output 13.6kw of heat to your pool !

Extremely Quiet Operation

The Thermotec Inverter range work very silently thanks to a unique internal ventilation system and the inverter technology.

Both the fan and compressor automatically adjust their speed to match the pool heat demand, therefore once the pool is up to temperature, the unit can operate with reduced power consumption and noise.

Colour Touch Screen Controls

The Thermotec Inverter have a unique 5″ colour backlit touch screen control/display panel

This provides easy to use controls

The display will show:-

  • The current pool water temperature
  • The mode (eg heating or cooling)
  • If the timer function has been set
  • If the fan is operating
  • The current time and date
  • The outside ambient temperature
  • If there is a fault, a fault code is displayed to explain the problem

In addition, the display can show:-

  • A graph of the temperature of the pool over time so that you can see how the pool temperature is being maintained by the Thermotec Inverter heat pump
  • A graph of the power consumed by the heat pump over time

The colour display is backlit making it easy to read in low light conditions and also in bright sunlight

Wi-Fi Control

The optional Wi-Fi module allows the Thermotec inverter Horizontal 9KW to be monitored and controlled from a smartphone or any internet web browser.

The Thermotec inverter Horizontal 9KW App is available for both Android and iPhone

The Wi-Fi module simply connects to the heat pump via the supplied cable

The module is then joined to your wi-fi network to allow it to communicate with the internet

The wifi module also allows HeatPumps4Pools to provide remote monitoring and support of your heat pump with the ability to change any settings if required. This greatly enhances the speed and efficiency of our technical support.

The Thermotec inverter Horizontal 9KW app can then be installed into your smart phone to give full remote control and monitoring of your pool heat pump.

Note: A a wifi signal is required at the location of the heat pump in order for the wifi module to be able to connect to your wifi.

Please test the strength of the wifi signal eg with a laptop or your smart phone before purchasing the wifi module.

If you do not have a wifi signal at the heat pump’s location, then you can either:-

  1. Use a wifi signal extender to boost the signal in the area of the heat pump
  2. Use power lan adaptors plugged into mains sockets in the house and the pool shed. You can then connect a wifi extended to the powerlan adaptor in your pool shed.

Using the app you can:-

  • Turn the heat pump on and off
  • See the current pool water temperature
  • Alter the desired pool set temperature
  • Set the timer
  • View the pool temperature history graph
  • Change the mode of the heat pump from heating, cooling and auto modes
  • Put the heat pump in and out of silence mode (eg for nightime use)
  • Show the weather temperatures and information
  • Display any error codes and messages

The Thermotec inverter Horizontal 9KW heat pump comes with:-

  • 2 x Water connection unions
  • 1 x Basic Winter cover
  • 4 x Rubber mounting feet



not rated £1,965.00 inc. VAT Add to basket
Thermotec Inverter Vertical 29KW
Thermotec Inverter Vertical 29KW

Thermotec inverter Vertical 29KW

New for 2018, the Thermotec Inverter range of pool heat pumps really do offer the best in terms of efficiency, performance, reliability and low noise operation.

The Thermotec Inverter range are fully inverter driven. This means that they automatically adjust the speed of the fan and compressor to precisely match the heat demand from the pool.

The ability to adjust the output of the heat pump allows the Thermotec inverter Vertical 29KW to deliver greatly reduced running costs with COPs of up to 13. This means that for every 1kw of electricity used by the heat pump, 13kw of heat is delivered to the pool. This delivers reduced running costs compared with other heat pumps on the market

In addition the inverter technology has a reduced electrical startup requirement, making them ideal for properties with a sensitive or limited electrical supply.

Features
  • Fully inverter driven with variable speed fan and compressor to deliver the lowest running costs with maximum heat output
  • High efficiency with COPs of up to 13. This means that for every 1kw of electricity used by the heat pump, 13kw of heat is returned to the pool.
  • The desired water temperature can be adjusted in steps of 0.1  °C.
  • Equipped with an easy to use 5-inch colour touch screen display / control panel.
  • Remote control and monitor your heat pump via an app on your smartphone
  • Top quality Mitsubishi variable speed inverter compressor
  • Brushless variable speed DC fan motor – very efficient with extremely quiet operation
  • Control panel is lockable to prevent tampering with the pool set temperature (useful for rented properties)
  • Display shows temperature & power consumption curves to monitor the performance of the heat pump
  • Six different models:9kw, 12kw, 17kw, 19.5kw, 24.2kw, 28 kw and 34kw
  • All models single phase power (ie 220v to 240v)
  • Suitable for pools, swim spas, hot tubs and koi ponds etc
  • Desired water temperature can be set from +10c to +40c
  • Soft start with reduced electrical startup requirements for properties with sensitive or limited power supplies
  • Low noise, variable speed fan.
  • Corrosion resistant case
  • Microprocessor controlled
  • Automatic hot gas defrosting.
  • Suitable for use on koi ponds
  • Titanium heat exchanger – resistant to corrosion from chlorine or salt pools.
  • Operates in air temperatures as low as -15  °C.
  • Capable of heating and cooling, all year round.
  • Optional wifi module – control the heat pump from your smartphone or any web browser
  • 3-Year Warranty

The sizing guide for a covered pool is:-

Model Kw
Recommended Max Pool Volume
 Absolute Max Pool Volume
Thermotec Inverter Horizontal 9kw 9kw 30m3 45m3
Thermotec Inverter Horizontal 12kw 12kw
40m3
60m3
Thermotec Inverter Horizontal 17kw 17kw
50m3
75m3
Thermotec Inverter Horizontal 20kw 19.5kw
65m3
95m3
Thermotec Inverter Horizontal 24kw 24.2kw
75m3
120m3
Thermotec Inverter Vertical 29kw 28.6kw
93m3
116m3
Thermotec Inverter Vertical 34kw 34kw 109m3 136m3
Thermotec Inverter Vertical 34kw (3-phase) 34kw 109m3 136m3



For a koi pond that is heated all year round with a winter temperature of around 12c and a summer temperature of around 20-22c, we recommend the following sizing:-

 Pond Sizing Guide
Model
Max Pond Volume
Thermotec Inverter Horizontal 9kw 4500 gallons
Thermotec Inverter Horizontal 12kw 6000 gallons
Thermotec Inverter Horizontal 17kw
7500 gallons
Thermotec Inverter Horizontal 19.5kw
9600 gallons
Thermotec Inverter Horizontal 24kw
11,600 gallons
Thermotec Inverter Vertical 29kw
13,800 gallons
Thermotec Inverter Vertical 34kw
19,900 gallons
Thermotec Inverter Vertical 34kw (3 Phase) 19,900 gallons

(Note: This assumes that the pond is covered in winter and that a temperature of +12c is to be maintained over winter)

COP And Performance

By using the latest inverter technology, the Thermotec Inverter canout perform traditional on/off type heat pumps as well as many other inverter driven models.

Even as the outside air temperature falls, the Thermotec Inverter will still perform well, delivering heat to your pool.

The Thermotec Inverter heat pumps can work well with outside air temperatures as low as -15c

The COP (Coefficient of Performance) is the ratio of the amount of heat (in kw) that the heat pump delivers to your pool compared to the electricity that the heat pump uses (in kw)

By using the latest inverter technology, the Thermotec Inverter has COPs up to 13.6. This means that in these conditions, 1kw of electricity consumed by the heat pump will output 13.6kw of heat to your pool !

Extremely Quiet Operation

The Thermotec Inverter range work very silently thanks to a unique internal ventilation system and the inverter technology.

Both the fan and compressor automatically adjust their speed to match the pool heat demand, therefore once the pool is up to temperature, the unit can operate with reduced power consumption and noise.

Colour Touch Screen Controls

The Thermotec Inverter have a unique 5″ colour backlit touch screen control/display panel

This provides easy to use controls

The display will show:-

  • The current pool water temperature
  • The mode (eg heating or cooling)
  • If the timer function has been set
  • If the fan is operating
  • The current time and date
  • The outside ambient temperature
  • If there is a fault, a fault code is displayed to explain the problem

In addition, the display can show:-

  • A graph of the temperature of the pool over time so that you can see how the pool temperature is being maintained by the Thermotec Inverter heat pump
  • A graph of the power consumed by the heat pump over time

The colour display is backlit making it easy to read in low light conditions and also in bright sunlight

Wi-Fi Control

The optional Wi-Fi module allows the Thermotec inverter Vertical 29KW to be monitored and controlled from a smartphone or any internet web browser.

The Thermotec inverter Vertical 29KW App is available for both Android and iPhone

The Wi-Fi module simply connects to the heat pump via the supplied cable

The module is then joined to your wi-fi network to allow it to communicate with the internet

The wifi module also allows HeatPumps4Pools to provide remote monitoring and support of your heat pump with the ability to change any settings if required. This greatly enhances the speed and efficiency of our technical support.

The Thermotec inverter Vertical 29KW app can then be installed into your smart phone to give full remote control and monitoring of your pool heat pump.

Note: A a wifi signal is required at the location of the heat pump in order for the wifi module to be able to connect to your wifi.

Please test the strength of the wifi signal eg with a laptop or your smart phone before purchasing the wifi module.

If you do not have a wifi signal at the heat pump’s location, then you can either:-

  1. Use a wifi signal extender to boost the signal in the area of the heat pump
  2. Use power lan adaptors plugged into mains sockets in the house and the pool shed. You can then connect a wifi extended to the powerlan adaptor in your pool shed.

Using the app you can:-

  • Turn the heat pump on and off
  • See the current pool water temperature
  • Alter the desired pool set temperature
  • Set the timer
  • View the pool temperature history graph
  • Change the mode of the heat pump from heating, cooling and auto modes
  • Put the heat pump in and out of silence mode (eg for nightime use)
  • Show the weather temperatures and information
  • Display any error codes and messages



not rated £4,315.00 inc. VAT Add to basket
Thermotec Inverter Vertical 34KW
Thermotec Inverter Vertical 34KW

Thermotec inverter Vertical 34KW

New for 2018, the Thermotec Inverter range of pool heat pumps really do offer the best in terms of efficiency, performance, reliability and low noise operation.

The Thermotec Inverter range are fully inverter driven. This means that they automatically adjust the speed of the fan and compressor to precisely match the heat demand from the pool.

The ability to adjust the output of the heat pump allows the Thermotec inverter Vertical 34KW to deliver greatly reduced running costs with COPs of up to 13. This means that for every 1kw of electricity used by the heat pump, 13kw of heat is delivered to the pool. This delivers reduced running costs compared with other heat pumps on the market

In addition the inverter technology has a reduced electrical startup requirement, making them ideal for properties with a sensitive or limited electrical supply.

Features
  • Fully inverter driven with variable speed fan and compressor to deliver the lowest running costs with maximum heat output
  • High efficiency with COPs of up to 13. This means that for every 1kw of electricity used by the heat pump, 13kw of heat is returned to the pool.
  • The desired water temperature can be adjusted in steps of 0.1  °C.
  • Equipped with an easy to use 5-inch colour touch screen display / control panel.
  • Remote control and monitor your heat pump via an app on your smartphone
  • Top quality Mitsubishi variable speed inverter compressor
  • Brushless variable speed DC fan motor – very efficient with extremely quiet operation
  • Control panel is lockable to prevent tampering with the pool set temperature (useful for rented properties)
  • Display shows temperature & power consumption curves to monitor the performance of the heat pump
  • Six different models:9kw, 12kw, 17kw, 19.5kw, 24.2kw, 28 kw and 34kw
  • All models single phase power (ie 220v to 240v)
  • Suitable for pools, swim spas, hot tubs and koi ponds etc
  • Desired water temperature can be set from +10c to +40c
  • Soft start with reduced electrical startup requirements for properties with sensitive or limited power supplies
  • Low noise, variable speed fan.
  • Corrosion resistant case
  • Microprocessor controlled
  • Automatic hot gas defrosting.
  • Suitable for use on koi ponds
  • Titanium heat exchanger – resistant to corrosion from chlorine or salt pools.
  • Operates in air temperatures as low as -15  °C.
  • Capable of heating and cooling, all year round.
  • Optional wifi module – control the heat pump from your smartphone or any web browser
  • 3-Year Warranty

The sizing guide for a covered pool is:-

Model Kw
Recommended Max Pool Volume
 Absolute Max Pool Volume
Thermotec Inverter Horizontal 9kw 9kw 30m3 45m3
Thermotec Inverter Horizontal 12kw 12kw
40m3
60m3
Thermotec Inverter Horizontal 17kw 17kw
50m3
75m3
Thermotec Inverter Horizontal 20kw 19.5kw
65m3
95m3
Thermotec Inverter Horizontal 24kw 24.2kw
75m3
120m3
Thermotec Inverter Vertical 29kw 28.6kw
93m3
116m3
Thermotec Inverter Vertical 34kw 34kw 109m3 136m3
Thermotec Inverter Vertical 34kw (3-phase) 34kw 109m3 136m3



For a koi pond that is heated all year round with a winter temperature of around 12c and a summer temperature of around 20-22c, we recommend the following sizing:-

 Pond Sizing Guide
Model
Max Pond Volume
Thermotec Inverter Horizontal 9kw 4500 gallons
Thermotec Inverter Horizontal 12kw 6000 gallons
Thermotec Inverter Horizontal 17kw
7500 gallons
Thermotec Inverter Horizontal 19.5kw
9600 gallons
Thermotec Inverter Horizontal 24kw
11,600 gallons
Thermotec Inverter Vertical 29kw
13,800 gallons
Thermotec Inverter Vertical 34kw
19,900 gallons
Thermotec Inverter Vertical 34kw (3 Phase) 19,900 gallons

(Note: This assumes that the pond is covered in winter and that a temperature of +12c is to be maintained over winter)

COP And Performance

By using the latest inverter technology, the Thermotec Inverter canout perform traditional on/off type heat pumps as well as many other inverter driven models.

Even as the outside air temperature falls, the Thermotec Inverter will still perform well, delivering heat to your pool.

The Thermotec Inverter heat pumps can work well with outside air temperatures as low as -15c

The COP (Coefficient of Performance) is the ratio of the amount of heat (in kw) that the heat pump delivers to your pool compared to the electricity that the heat pump uses (in kw)

By using the latest inverter technology, the Thermotec Inverter has COPs up to 13.6. This means that in these conditions, 1kw of electricity consumed by the heat pump will output 13.6kw of heat to your pool !

Extremely Quiet Operation

The Thermotec Inverter range work very silently thanks to a unique internal ventilation system and the inverter technology.

Both the fan and compressor automatically adjust their speed to match the pool heat demand, therefore once the pool is up to temperature, the unit can operate with reduced power consumption and noise.

Colour Touch Screen Controls

The Thermotec Inverter have a unique 5″ colour backlit touch screen control/display panel

This provides easy to use controls

The display will show:-

  • The current pool water temperature
  • The mode (eg heating or cooling)
  • If the timer function has been set
  • If the fan is operating
  • The current time and date
  • The outside ambient temperature
  • If there is a fault, a fault code is displayed to explain the problem

In addition, the display can show:-

  • A graph of the temperature of the pool over time so that you can see how the pool temperature is being maintained by the Thermotec Inverter heat pump
  • A graph of the power consumed by the heat pump over time

The colour display is backlit making it easy to read in low light conditions and also in bright sunlight

Wi-Fi Control

The optional Wi-Fi module allows the Thermotec inverter Vertical 34KW to be monitored and controlled from a smartphone or any internet web browser.

The Thermotec inverter Vertical 34KW App is available for both Android and iPhone

The Wi-Fi module simply connects to the heat pump via the supplied cable

The module is then joined to your wi-fi network to allow it to communicate with the internet

The wifi module also allows HeatPumps4Pools to provide remote monitoring and support of your heat pump with the ability to change any settings if required. This greatly enhances the speed and efficiency of our technical support.

The Thermotec inverter Vertical 34KW app can then be installed into your smart phone to give full remote control and monitoring of your pool heat pump.

Note: A a wifi signal is required at the location of the heat pump in order for the wifi module to be able to connect to your wifi.

Please test the strength of the wifi signal eg with a laptop or your smart phone before purchasing the wifi module.

If you do not have a wifi signal at the heat pump’s location, then you can either:-

  1. Use a wifi signal extender to boost the signal in the area of the heat pump
  2. Use power lan adaptors plugged into mains sockets in the house and the pool shed. You can then connect a wifi extended to the powerlan adaptor in your pool shed.

Using the app you can:-

  • Turn the heat pump on and off
  • See the current pool water temperature
  • Alter the desired pool set temperature
  • Set the timer
  • View the pool temperature history graph
  • Change the mode of the heat pump from heating, cooling and auto modes
  • Put the heat pump in and out of silence mode (eg for nightime use)
  • Show the weather temperatures and information
  • Display any error codes and messages



not rated £4,965.00 inc. VAT Add to basket
Thermotec Inverter Vertical 34KW
Thermotec Inverter Vertical 34KW (3-Phase)

Thermotec inverter Vertical 34KW (3-Phase)

New for 2018, the Thermotec Inverter range of pool heat pumps really do offer the best in terms of efficiency, performance, reliability and low noise operation.

The Thermotec Inverter range are fully inverter driven. This means that they automatically adjust the speed of the fan and compressor to precisely match the heat demand from the pool.

The ability to adjust the output of the heat pump allows the Thermotec inverter Vertical 34KW to deliver greatly reduced running costs with COPs of up to 13. This means that for every 1kw of electricity used by the heat pump, 13kw of heat is delivered to the pool. This delivers reduced running costs compared with other heat pumps on the market

In addition the inverter technology has a reduced electrical startup requirement, making them ideal for properties with a sensitive or limited electrical supply.

Features
  • Fully inverter driven with variable speed fan and compressor to deliver the lowest running costs with maximum heat output
  • High efficiency with COPs of up to 13. This means that for every 1kw of electricity used by the heat pump, 13kw of heat is returned to the pool.
  • The desired water temperature can be adjusted in steps of 0.1  °C.
  • Equipped with an easy to use 5-inch colour touch screen display / control panel.
  • Remote control and monitor your heat pump via an app on your smartphone
  • Top quality Mitsubishi variable speed inverter compressor
  • Brushless variable speed DC fan motor – very efficient with extremely quiet operation
  • Control panel is lockable to prevent tampering with the pool set temperature (useful for rented properties)
  • Display shows temperature & power consumption curves to monitor the performance of the heat pump
  • Six different models:9kw, 12kw, 17kw, 19.5kw, 24.2kw, 28 kw and 34kw
  • All models single phase power (ie 220v to 240v)
  • Suitable for pools, swim spas, hot tubs and koi ponds etc
  • Desired water temperature can be set from +10c to +40c
  • Soft start with reduced electrical startup requirements for properties with sensitive or limited power supplies
  • Low noise, variable speed fan.
  • Corrosion resistant case
  • Microprocessor controlled
  • Automatic hot gas defrosting.
  • Suitable for use on koi ponds
  • Titanium heat exchanger – resistant to corrosion from chlorine or salt pools.
  • Operates in air temperatures as low as -15  °C.
  • Capable of heating and cooling, all year round.
  • Optional wifi module – control the heat pump from your smartphone or any web browser
  • 3-Year Warranty

The sizing guide for a covered pool is:-

Model Kw
Recommended Max Pool Volume
 Absolute Max Pool Volume
Thermotec Inverter Horizontal 9kw 9kw 30m3 45m3
Thermotec Inverter Horizontal 12kw 12kw
40m3
60m3
Thermotec Inverter Horizontal 17kw 17kw
50m3
75m3
Thermotec Inverter Horizontal 20kw 19.5kw
65m3
95m3
Thermotec Inverter Horizontal 24kw 24.2kw
75m3
120m3
Thermotec Inverter Vertical 29kw 28.6kw
93m3
116m3
Thermotec Inverter Vertical 34kw 34kw 109m3 136m3
Thermotec Inverter Vertical 34kw (3-phase) 34kw 109m3 136m3



For a koi pond that is heated all year round with a winter temperature of around 12c and a summer temperature of around 20-22c, we recommend the following sizing:-

 Pond Sizing Guide
Model
Max Pond Volume
Thermotec Inverter Horizontal 9kw 4500 gallons
Thermotec Inverter Horizontal 12kw 6000 gallons
Thermotec Inverter Horizontal 17kw
7500 gallons
Thermotec Inverter Horizontal 19.5kw
9600 gallons
Thermotec Inverter Horizontal 24kw
11,600 gallons
Thermotec Inverter Vertical 29kw
13,800 gallons
Thermotec Inverter Vertical 34kw
19,900 gallons
Thermotec Inverter Vertical 34kw (3 Phase) 19,900 gallons

(Note: This assumes that the pond is covered in winter and that a temperature of +12c is to be maintained over winter)

COP And Performance

By using the latest inverter technology, the Thermotec Inverter canout perform traditional on/off type heat pumps as well as many other inverter driven models.

Even as the outside air temperature falls, the Thermotec Inverter will still perform well, delivering heat to your pool.

The Thermotec Inverter heat pumps can work well with outside air temperatures as low as -15c

The COP (Coefficient of Performance) is the ratio of the amount of heat (in kw) that the heat pump delivers to your pool compared to the electricity that the heat pump uses (in kw)

By using the latest inverter technology, the Thermotec Inverter has COPs up to 13.6. This means that in these conditions, 1kw of electricity consumed by the heat pump will output 13.6kw of heat to your pool !

Extremely Quiet Operation

The Thermotec Inverter range work very silently thanks to a unique internal ventilation system and the inverter technology.

Both the fan and compressor automatically adjust their speed to match the pool heat demand, therefore once the pool is up to temperature, the unit can operate with reduced power consumption and noise.

Colour Touch Screen Controls

The Thermotec Inverter have a unique 5″ colour backlit touch screen control/display panel

This provides easy to use controls

The display will show:-

  • The current pool water temperature
  • The mode (eg heating or cooling)
  • If the timer function has been set
  • If the fan is operating
  • The current time and date
  • The outside ambient temperature
  • If there is a fault, a fault code is displayed to explain the problem

In addition, the display can show:-

  • A graph of the temperature of the pool over time so that you can see how the pool temperature is being maintained by the Thermotec Inverter heat pump
  • A graph of the power consumed by the heat pump over time

The colour display is backlit making it easy to read in low light conditions and also in bright sunlight

Wi-Fi Control

The optional Wi-Fi module allows the Thermotec inverter Vertical 34KW to be monitored and controlled from a smartphone or any internet web browser.

The Thermotec inverter Vertical 34KW App is available for both Android and iPhone

The Wi-Fi module simply connects to the heat pump via the supplied cable

The module is then joined to your wi-fi network to allow it to communicate with the internet

The wifi module also allows HeatPumps4Pools to provide remote monitoring and support of your heat pump with the ability to change any settings if required. This greatly enhances the speed and efficiency of our technical support.

The Thermotec inverter Vertical 34KW app can then be installed into your smart phone to give full remote control and monitoring of your pool heat pump.

Note: A a wifi signal is required at the location of the heat pump in order for the wifi module to be able to connect to your wifi.

Please test the strength of the wifi signal eg with a laptop or your smart phone before purchasing the wifi module.

If you do not have a wifi signal at the heat pump’s location, then you can either:-

  1. Use a wifi signal extender to boost the signal in the area of the heat pump
  2. Use power lan adaptors plugged into mains sockets in the house and the pool shed. You can then connect a wifi extended to the powerlan adaptor in your pool shed.

Using the app you can:-

  • Turn the heat pump on and off
  • See the current pool water temperature
  • Alter the desired pool set temperature
  • Set the timer
  • View the pool temperature history graph
  • Change the mode of the heat pump from heating, cooling and auto modes
  • Put the heat pump in and out of silence mode (eg for nightime use)
  • Show the weather temperatures and information
  • Display any error codes and messages



not rated £5,135.00 inc. VAT Add to basket
