Delta UV EA Series Quartz Sleeve Replacements
Delta UV EA Series Quartz Sleeve Replacements
A new series of professional Stainless Steel UVC-units for ponds, pools, whirpools etc. The Delta Ultraviolet’s Elektra® Pro Delta Bio-UV series of UV sanitizers have been in production since 1999. These 100% Stainless Steel housing systems have become the “Cadillac” of UV sanitizers for the Koi Pond industry and have gained a reputation second to none for quality, functionality, performance and reliability.
Five different model sizes are available for circulation systems with water flow rates from 800 GPH (3,600 LPH) to 3,450 GPH (15,600 LPH). All models are available in 120V and 240V 50/60 Hz electrical ratings for worldwide application.
Exclusive features, as mentioned above include a 316 stainless steel housing that allows for 360° rotation of the inlet and outlet unions for ease of installation. Another key exclusive feature not commonly found in similar units is the inclusion of unions at each end of the stainless steel housing to facilitate cleaning of the quartz tube, should it be necessary.
As you can clearly see from the image below these UV’s can be mounted either vertically or horizontally.
Like all Delta Ultraviolet systems, Delta’s propriety High Output (HO) low pressure lamp is capable of 30,000 µ/sec./cm2 output lamp end-of-life (EOL) when design flow rates are maintained. This is the same requirement for Class A drinking water. The long life lamp is rated at 9000 hours of continuous use (approximately 1 year).
Delta UV EA Series Technical data
| Type | Pond Size | Max Pressure | Flow Rate | UV-C Dose | Dia | UV Lamps |
|---|---|---|---|---|---|---|
| Delta UV EA-3H-5 | Up to 1500 gallons | 3 Bar | 2400 lph | 30mJ/cm2 | 75 mm | 1 x 35 watt |
| Type | Pond Size | Max Pressure | Flow Rate | UV-C Dose | Dia | UV Lamps |
|---|---|---|---|---|---|---|
| Delta UV EA-4H-15 | Up to 4500 gallons | 3 Bar | 7600 lph | 30mJ/cm2 | 100 mm | 1 x 55 watt |
| Delta UV EA-4H-20 | Up to 6000 gallons | 3 Bar | 9500 lph | 30mJ/cm2 | 100 mm | 1 x 90 watt |
| Delta UV EA-4H-40 | Up to 7000 gallons | 3 Bar | 10700 lph | 30mJ/cm2 | 100 mm | 1 x 110 watt |
Delta UV EA Series Quartz Sleeve Replacements and not the actual units
Green Filter replacement Parts
Green Filter replacement Parts
These new Green Reset Pond Filters introduce a new era in pond keeping. This new external pressurized UVC Bio-filter is available in 4 models – 25L, 40L, 60L & 100L – with great filtration capacity for small and large ponds. First, the water is forced through the sponges (mechanical filtration) and then through the bioballs (biological filtration) in combination with an effective UVC sterilizer lamp to guarantee crystal clear pond water.
The innovative design of the Green Reset makes maintenance operations simple and quick. 3 simple steps make cleaning a breeze:
1) Lift the handle on the top of the cover.
2) Turn the lateral grip handles in the cleaning position and, then, the flow selector handle.
3) Push the big handle down to squeeze the internal sponges (patented mechanism).
Hi Blow 40 Diaphragm Replacement (2 Part)
Hi Blow 40 Diaphragm Replacement
Set of two diaphragms to fit the Hiblow range of Air Pumps.
Hi Blow 80 Diaphragm Replacement (2 Part)
Hi Blow 80 Diaphragm Replacement
Set of two diaphragms to fit the Hiblow range of Air Pumps.
Koi Pro Air-Blow 50 Diaphragm Set
Koi Pro Air-Blow 50 Diaphragm Set
The Koi Pro Air-Blow 50 Air Pump has been professionally designed and constructed to develop high output and delivers great performance to depths of up to 3 metres. This is a revolutionary product in it’s class which easily out performs conventional and motor driven air pumps often used in aquaculture.
The Koi Pro Air-Blow Air Pump is compact, reliable, powerful, and ultra quiet. The pump is also economical to run consuming only 35 watts.
There are no sliding parts with the Koi Pro, hence there is no need for lubrication, unlike some conventional designs which can transfer oil contaminated air into the environment. The other advantage of course is that the exhausted air is also clean, making this a good choice for clean environments.
Product Features:
- Professionally constructed design
- Ultra quiet in operation
- Lubrication free
- 50 litres of air per minute output
- Output depths up to 3 metres
- 35 watt power consumption
| Airflow: | 50 Litres / min at 3m depth |
| Voltage: | 110v / 230v |
| Wattage: | 35 watts |
| Warranty: | 12 Months Manufacturers Warranty |
Medo 100-120 Service Kit
Medo 100-120 Service Kit
we supply a full range of service kits for your Medo Air Pumps. Like anything else with moving parts, maintenance is required in order to keep your Medo Air Pump working at optimum performance.
Regular servicing, recommended annually, can prolong the life expectancy of your pump.
Medo 28 Service Kit
Medo 28 Service Kit
we supply a full range of service kits for your Medo Air Pumps. Like anything else with moving parts, maintenance is required in order to keep your Medo Air Pump working at optimum performance.
Regular servicing, recommended annually, can prolong the life expectancy of your pump.
Medo 45 Replacement Filter Foam
Medo 45 Replacement Filter Foam
This is a replacement air filter sponge for the Medo – Piston Driven pumps.
Over time pumps output will be reduced due to the clogging of the Filters.
It is advised to change the filter periodically.
Medo 45 Service Kit
Medo 45 Service Kit
we supply a full range of service kits for your Medo Air Pumps. Like anything else with moving parts, maintenance is required in order to keep your Medo Air Pump working at optimum performance.
Regular servicing, recommended annually, can prolong the life expectancy of your pump.
Medo 80 Replacement Filter Foam
Medo 80 Replacement Filter Foam
This is a replacement air filter sponge for the Medo – Piston Driven pumps.
Over time pumps output will be reduced due to the clogging of the Filters.
It is advised to change the filter periodically.
Medo 80 Service Kit
Medo 80 Service Kit
we supply a full range of service kits for your Medo Air Pumps. Like anything else with moving parts, maintenance is required in order to keep your Medo Air Pump working at optimum performance.
Regular servicing, recommended annually, can prolong the life expectancy of your pump.
Oase BioTec 80000 Filter Cartridge Set
Oase BioTec 80000 Filter Cartridge Set
- Genuine Oase replacement cartridge set
- 2 x Coarse grade filter foams (Blue)
- 2 x Medium Grade filter foams (Purple)
- 2 x Fine Grade filter foams (Red)
- Each filter foam is supplied with attaching clip
The BioTec Premium 80000 Filter Cartridge Set is a genuine Oase replacement product.
Superb filtration results are achieved thanks to the 3 different grades of foam; Coarse (blue), medium (purple) and fine (red). Each grade of foam provides a different level of debris extraction along with a significant biological surface area whilst all the time ensuring consistent unhindered flow-through rates through the filter.
In order to ensure the optimum performance of your Oase pond filter, it is crucial that genuine Oase sponges are used. Cheaper replica parts will produce poor filtration results and invalidate the Oase Clearwater Guarantee.
Oase ProfiClear Premium-Compact-L Replacement Sieve Set 150 micron
Oase ProfiClear Premium-Compact-L Replacement Sieve Set 150 micron
- Genuine Oase spare part
- 150 Micron
- Supplied as a set of 8
This is a genuine Oase Replacement Sieve Set for use with the Oase range of Drum Filters
These high quality replacement Filter Screens remove waste down to 150μ, providing outstanding mechanical filtration results.
Sold as a complete set of 8 Filter Screens the they are suitable for the following Oase Products:
- Oase ProfiClear Premium
- Oase ProfiClear Compact-L
Oase ProfiClear Premium-Compact-L Replacement Sieve Set 30 micron
Oase ProfiClear Premium-Compact-L Replacement Sieve Set 30 micron
- Genuine Oase spare part
- 30 Micron
- Supplied as a set of 8
This is a genuine Oase Replacement Sieve Set for use with the Oase range of Drum Filters
These high quality replacement Filter Screens remove waste down to 30μ, providing outstanding mechanical filtration results.
Sold as a complete set of 8 Filter Screens the they are suitable for the following Oase Products:
- Oase ProfiClear Premium
- Oase ProfiClear Compact-L
Oase ProfiClear Premium-Compact-L Replacement Sieve Set 60 micron
Oase ProfiClear Premium-Compact-L Replacement Sieve Set 60 micron
- Genuine Oase spare part
- 60 Micron
- Supplied as a set of 8
This is a genuine Oase Replacement Sieve Set for use with the Oase range of Drum Filters
These high quality replacement Filter Screens remove waste down to 60μ, providing outstanding mechanical filtration results.
Sold as a complete set of 8 Filter Screens the they are suitable for the following Oase Products:
- Oase ProfiClear Premium
- Oase ProfiClear Compact-L
Oase Swim Skim 25 Replacement Foam
Oase Swim Skim 25 Replacement Foam
This is a Replacement Foam for the Oase SwimSkim 25 Pond Skimmer.
Oase Swim Skim 50 Replacement Foam
Oase Swim Skim 50 Replacement Foam
This is a Replacement Foam for the Oase SwimSkim 50 and CWS Pond Skimmers.
Yamitsu Algae Master Pond UV Clarifier Replacement Electrics
Yamitsu Algae Master Pond UV Clarifier Replacement Electrics
Yamitsu algae master uv’s are made from UV stabilised materials to ensure a longer life and incorporate turbulators to enhance the unit’s performance. Large inlet and exhaust ports make the algae master uv suitable for a wide range of pond uv applications. It is recommended that the algae master uv should be installed using solid solvent weld pipe.
However, all algae master uv’s come complete with free (glue in) hosetails enabling them to be connected to ½”, ¾”, 1″, 1¼” and 1½” flexible pipe. Algae master uv’s will also fit most popular 1½” household solvent weld waste and pressure pipes.
Yamitsu Algae Master Pond UV Clarifier Installation
If you have a severe algae problem you should effect a partial water change before starting the installation. Yamitsu Algae Master Pond UV can be added to any existing filtration system. For best results algae master units should be fitted in line, after the pump, with water being forced through them. Use the largest size of pipe possible. If hosetails are to be used, it is very important that they are trimmed to the largest possible size that will fit inside the flexible pipe (before glueing in place). This will ensure that the maximum flow rate can be obtained for the size of pipe.
Yamitsu Algae Master UV Maintenance
Although maintenance is minimal all UV lamps need replacing at six monthly intervals. The algae master’s uv lamp may be illuminated and appear to be working but the radiation dosage diminishes with age and is ineffective after six months. Dispose of used uv lamps sensibly. Even exhausted uv lamps should NEVER be looked at directly when illuminated.
As the algae master uv is dependant upon water passing through it, it is important to ensure that any pump strainers, pre-filters or delivery pipes are not blocked or are causing the flow to be restricted.
| ||||||||||||||
This is the Yamitsu Algae Master Pond UV Clarifier Replacement Electrics and not the actual unit !
Yamitsu Quartz Sleeves
Yamitsu Quartz Sleeves
For those Koi and pond enthusiasts who are not as careful at they might be, we do also sell the spare Yamitsu Quartz Sleeves in the most standard sizes.
The Yamitsu Quartz Sleeve insulates the lamp from the water, allowing the lamp to operate at the optimum performance.
The ultraviolet lamp will remain independent of the flow of water. Yamitsu Quartz Sleeves are of open ended construction and are made from pure fused quartz.
Quartz is extremely transparent over a wide spectral range, with a low coefficient of thermal expansion and quartz is resistant to scratching and thermal shock. Fused quartz is made form crushing and melting natural materials. The purity of quartz is paramount to the efficiency of the lamp and sleeve.
Yamitsu Quartz Sleeve Beneffits :
- Greater ultraviolet transmission
- Low coefficient of thermal expansion
- Increased hardness and resistance to scratching
- Higher resistance to solarisation or darkening from ultraviolet radiation
Quartz sleeves are available for the Yamitsu Algae Master Pond UV Clarifier 6, 8, 11, 15, 25, 30 and 55 watt units.
Oase Filtoclear 12000 (Replacement Foam)
Oase Filtoclear 12000
The Oase Filtoclear 12000 Pond Filter is a highly developed pressure filter designed with ease of use and quality filtration in mind.
Pond water is pumped into a sealed filter unit creating a pressure of up to 0.2 bar. This in turn means that water leaves the filter under pressure, allowing the water to be pushed up to a waterfall, unlike a conventional gravity return filter, which must always be positioned at the highest point of the system.
The Filtoclear pressure filter also has been designed with all the connections and major operating elements in the lid allowing the filter to be partly buried out of sight
- Pressurised Filter – Pressurised Outlet
- Cleaning System – For ease of maintenance
- Attach a hose to discharge waste into drain
- Safety catch on tension ring
- Bitron UVC Integrated clarifier
- Complete Filtration Packages
Summary:
- Small dimensions, can be integrated into any garden landscape
- Typically OASE: highest quality materials
- Guaranteed clear water due to the ideal combination of mechanical, biological and UVC filtration in one system
- The UVC rays reduce pathogens and flocculate algae cells thus allowing their removal from the water
- The pressure created by the filter pump can be utilised to power a stream or waterfall
- The “Easy-Clean-Technology“ makes cleaning the filter simple!
The Filtoclear range embodies a new generation of pressure filters, which is unrivalled in respect of filter characteristics and operating comfort.
OASE Filtoclear Feature’s | Filtoclear 3000 | Filtoclear 6000 | Filtoclear 12000 | Filtoclear 16000 | Filtoclear 20000 | Filtoclear 30000 | |||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Cable length | 5m | 5m | 5m | 5m | 5m | 5m | |||||||||||||||||||||||||||||
Guarantee | 2 years | 2 years | 2 years | 2 years | 2 years | 2 years | |||||||||||||||||||||||||||||
(Ø x H) mm | 380 x 310 | 380 x 430 | 380 x 550 | 380 x 670 | 380 x 750 | 380 x 750 | |||||||||||||||||||||||||||||
Inlet and outlet | 3/4“ up to 1.5“ | 3/4“ up to 1.5“ | 3/4“ up to 1.5“ | 3/4“ up to 1.5“ | 1 1/2 up to 2 ” | 1 1/2 up to 2 ” | |||||||||||||||||||||||||||||
Suitable for Ponds up to | 3000 ltrs | 6000 ltrs | 12000 ltrs | 16000 ltrs | 20000 ltrs | 30000 ltrs | |||||||||||||||||||||||||||||
Integrated UV clarifier | 9 watt | 11 watt | 18 watt | 24 watt | 36 watt | 55 watt | |||||||||||||||||||||||||||||
Weight (kg) | 5.58 | 6.18 | 6.8 | 7.3 | 12 | 12 | |||||||||||||||||||||||||||||
Suitable for koi ponds | 3000 ltrs | 4000 ltrs | 5000 ltrs | 7500 ltrs | |||||||||||||||||||||||||||||||
