Aqua-Forte FC-301E Flow Controller for DM-E Pumps

Blue Eco Pump 2200 Watt

Cotswold Koi are proud to introduce the New Blue Eco Pump 2200 watt with exclusive True sine wave technology.

The  Blue ECO Titanium pumps are the most ECO friendly electric pumps produced. They utilise brushless DC electric motor technology, and have an efficiency rating of 94.6% – this compares with normal electric motors with have an efficiency of 45 – 50%. The power and therefore energy consumption is fully adjustable from 10 – 100% of full power, so when reducing the R.P.M the energy consumption reduces accordingly. The pumps produce very little heat as 94% of the energy used goes to turn the impellor, which makes them ideal for dry applications.

The  Blue Eco Pumps have an efficiency up to 94.6 %. The Blue Eco Pumps are whisper quite and come complete with seperate control unit.

Available in 240 watt, 320 watt, 500 watt, 900 watt, 1500 watt.

The Blue Eco Pumps are marine water resistant and can be used submersible and also in dry circumstances, even the controller is watertight. The controller display’s power used in watts, rpm and running hours.

The Blue Eco Pumps have dry running protection with life time bearing guarantee.

Blue Eco Pumps can be regulated from 0 up to maximum and even a 1500 watt Pump can run at an efficiency of over 90% at 35 watt and will take the same energy as a small pump and produce even more water.

All bigger pumps can be delivered with an adjustable impeller to improve also the efficiency in all circumstances.

The Blue Eco Pumps have been tested in practice for over one year by independent customers with 0 % failure.

The Blue Eco Pumps come complete with controller and 10 meter marine and chlorined water resistant cable.

The Blue Eco Pumps with an efficiency of 94.6 % are the only pumps at this moment world wide that work with True sine wave for better starting in difficult circumstances. True sine wave Blue Eco Pumps have a enormous starting torque.

Model

Blue Eco Pump Applications:

Given the fact that these pumps are suited for dry and wet use makes them extremely versatile for all kinds of applications: ponds, swimming pools, (marine) aquaria, industrial, etc. Saving energy is and becomes more and more important. A nice example of using the Blue Eco Pump is for bead filter system. In filter mode, a low R.P.M. position can be used to save energy for 99,9% of the time! Only during backwash the full power of the Blue Eco Pump will be used for a effective backwash procedure.

• Can be used dry or submersible
• Blue Eco Pump have no seals
• Have a hollow shaft for flushing
• Silicone O-rings
• Can be used in pure marine water
• Pumps are tested for over 1 year in extreme circumstances
• Tested in factory for hours before delivery with an exlusive report for each pump
• Complete with 10 meter of high quality water resistant cable
• Made of plastic, marine waterproof
• All our pumps are Tru sine wave technology developed by Toshiba and Siemens
• Control Unit shows Power Used (watts) hour counter and rpm
• Basket prefilters can be screwed on directly on the pump
• All pumps have rubbers for the feet.
• Fully CE approved for save operation
• 2 years garantee

The Blue Eco Pump 240 watt Pump takes only 10-15 watt at 300 rpm and have an efficiency of over 90%, furthermore the Blue Eco Pump500 and 900 watt pumps have an efficiency of even 94%

The bearing system of 500, 900, 1500 watt pumps are all exactly the same and thanks to True sine wave technology our starting torque is extremely high starting at 0 rpm.

The Blue Eco Pump 500 and 900 watt pumps can be software protected against running dry (extending bearing life) The Blue Eco Pump controller has programmable timers for programming only one time for every season and also Cruise control of the pump.

Blue Eco pumps are provided with an unbreakable shaft of titanium and all bearings are made of silicium carbide added with 15% carbon, the Rotors are made of titanium and Carbon (3 times stronger than steel)

The Superfish Pond ECO Plus RC 20000 Pump is now available with remote control that enables you to easily adjust your pond pump flow capacity.

The remote control enables you to switch your pump on/off and set the water flow rate of your Superfish Pond ECO Plus RC 20000 Pump to the required level of flow rate. This is the most economical to run pond pump as the slower the flow rate, the less wattage your pump uses.

These great economic to run, energy efficient Superfish Pond ECO Plus RC 20000 Pumps are suitable for dry-mounting and submerged use.

• High water flow output with an extreme low energy consumption.
• Suitable for both submerged and dry standing usage.
• Run Dry Protection, when there is no water the pump stops automatically.

Run Dry and overload protection

The pump is equipped with Run Dry Protection, 10 seconds after being taken away from water, the water pump will stop to protect it from running dry, it will try to re start after 10 seconds, if without water, it will stop again, this cycle will repeat 5 times, then the pump will stop. To re-start the pump take plug from main and plug back in and ensure pump is working well.

The pump has a thermal overload safety device. In the event of any overheating of the motor, this device automatically switches off the pump. The cooling time is roughly 15 to 20 minutes, then the pump automatically comes on again. If the overload cutout is tripped, it is essential to identify and deal with the cause of the overheating.

Superfish Pond ECO Plus RC 20000 Performance

• 8000 l/h – 2.5m max head – 23 watt
• 8300 l/h – 2.7m max head – 30 watt
• 9100 l/h – 3.2m max head – 43 watt
• 10000 l/h – 3.7m max head – 51 watt
• 11000 l/h – 4.2m max head – 62 watt
• 11500 l/h – 4.7m max head – 75 watt
• 12000 l/h – 5.2m max head – 90 watt
• 12700 l/h – 5.7m max head – 105 watt
• 13300 l/h – 6.0m max head – 115 watt
• 15000 l/h – 6.5m max head – 130 watt

Complete with 2 year manufacturer warranty.

Oase ProfiSkim Premium

The Oase ProfiSkim Premium can be used with large filter systems and in shallow water areas. The ProfiSkim Premium has the perfect dimensions for large quantities of water powerfully cleaning pond surfaces of up to 65 m2.

Characteristics:

• Ideal implementation in shallow water zones
• Can be used in gravity-fed operation (DN 110) or pump-fed operation, incl. 2″ (50 mm) adapter
• Water routing for effective suction capacity
• Perfect supplement for filter systems in the gravity fed, as well as the pump fed system
• Large, easy to clean stainless steel basket with 8 mm mesh width

• Powerful suction cleaning of pond surfaces up to 65 m2

• With stable stainless steel base
• On request, a basket with a 2 mm mesh width is available

AquaMax Eco Premium 12000

AquaMax Eco Premium 12000. With its elegant design, the new original is a real power saver compared to the previous model: The powerful delivery rate of 12000 l / h remains, but with a power consumption of only 110 W, this filter pump now consumes even less energy. It receives the additional energy bonus through the patented “Seasonal Flow Control” function, which can save a further 30% electricity thanks to intelligent water volume regulation. The additional connection option for optional filter accessories at the second, patented input is particularly effective in terms of functionality. In this way, dirt particles up to 11 mm in size can not only be removed from the pond floor, but also from the pond edge with a satellite filter or from the water surface with a surface skimmer. Further advantages are the convenient operation and the innovative frost protection, with which the pump can remain in the pond down to -20 ° C. Trust in OASE quality, because you receive a total of up to 5 years guarantee – 3 plus 2 years guarantee.

Characteristics:

• Outstanding energy balance: AquaMax Eco Premium 12000 has reliable displacement using even less energy
• Supplemental, patented connection of optional filter accessories for debris supply from more distant pond zones
• Unique, patented frost protection: the pump will not be damaged at temperatures as low as -20° C
• Flow rate can be mechanically and electronically adjusted
• Elegant design with clever operating elements
• Quiet for dry setup on swim ponds and bathing ponds
• »Environmental Function Control« (EFC by OASE) protects against dry run and blocking
• MADE IN GERMANY: precise and reliable German engineering at a high level of quality
• Displace plant remains or fish waste up to 10 mm in size
