Oase Biotec Screenmatic2 140000
Oase Biotec Screenmatic2 140000
OASE German Engineers have completely overhauled the highly successful BioTec 36 ScreenMatic filter and have released the innovative BioTec ScreenMatic² 140000 Pond Filter. This large, compact gravity outlet, flow-through filter box features an automated pre-filter conveyor which will screen out larger debris and transport this on a porous conveyor belt to a large collection basket for periodic emptying. The new Screendrive mechanism is now fully automated via a special cleaning sensor which controls the belt functions depending on the dirt level detected on the porous belt. Only small particles pass through the ScreenMatic drive belt where the large surface area biological/mechanical filter foams will trap and break down the organic waste. This innovative mechanism places far less biological load on the filter foams, meaning less maintenance and crystal clear water quality in ornamental, Goldfish and Koi ponds alike.
The OASE BioTec ScreenMatic² 140000 is a large, intelligent, flow-through pond filter that provides automated mechanical waste removal and biological filtration. The water enters the filter via a flow spreader onto a 300 micron fabric belt which strains out solid waste particles. When sufficiently soiled, a sensor engages the motor which performs a cleaning cycle, transferring the accumulated waste into a collection tray below the screen. The control display also allows instant cleaning cycles at the press of a button. The waste sensor can be adjusted backward and forward to alter cleaning regularity based on waste accumulation. A cleaning brush is supplied to keep the fabric screen free of entrapped dirt.
After mechanical straining, water enters the the biological media, a series of 18 large filter sponges differing in coarseness. The blue foams are rough, violet are medium fine and red are very fine grade. These sponges provide an abundance of surface for aerobic bacteria to populate and breakdown soluble waste pollutants. Cleaning the foams is made easy by the compression handle used to push down on the foams to release any build up of organic waste. Water is then directed through 12 cartridges containing 14.5kg of granulate media (zeolite), binding unwanted nutrients and trace ammonia before returning water to the pond.
- Incl. OASE Clear Water Guarantee
- Significantly less maintenance is required, thanks to coarse debris extraction
- More convenience, thanks to automatically driven self cleaning of the belt filter. Adjustable cleaning Sensor controls the belt run, depending on the degree of pollution. Incl. LED function check
- Cleaning of filter sponges directly in the filter, without removal
- Sludge drain with slide valve for removing debris from the filter system
- Different filter media for optimal development of filter bacteria
- Use of the PhosLess filter media tubes as needed for string algae reduction (optional accessory)
- Optimally matched to OASE AquaMax Eco filter pumps
- Direct connection possibility for Bitron C and Eco UVC clarifiers
- Reinforced strap material for an extended service life
- Double-sealed motor for an extended service life
- Water distributor without danger of clogging: Distributes the water uniformly on the belt filter
- Sludge basket with greater volume and simplified handling
- Rubberised separating lip for outstanding separation result
- Free brush for occasional cleaning of the belt filter
- Manual belt run now possible via button
- Highly effective flow-through filter for ponds up to 140.0 m³
-
Dimensions (L x W x H) mm 1200 x 800 x 760 Rated voltage (primary, secondary) 230 V / 50 Hz, 12 V / AC Power consumption W 5 Cable length 12 V device (with power unit) m 2.10 (Power unit) + 5.00 Net weight kg 105.00 Guarantee Years 2 + 1 Number of filter foams, total Units 18 Number of blue filter foams Units 4 Number of red filter foams Units 7 Number of purple filter foams Units 7 Special filter granulate kg 14.50 Temperature display No Coarse debris extraction µm 300 Inlet connections mm 25 / 32 / 38 / 50 Inlet connections 1″, 1 ¼”, 1 ½”, 2″ Outlet connections DN 110 Sludge discharge connections DN 75 Min. flow rate l/h 8000 Max. flow rate l/h 17500 Suitable for ponds up to max. m³ 140.0 Suitable for ponds with fish stock m³ 70.0 Suitable for ponds with koi stock m³ 35.0 Connection to Bitron C 36 – 110 W, Bitron Eco 120 – 240 W
Oase Biotec Screenmatic2 40000
Oase Biotec Screenmatic2 40000
OASE German Engineers have completely overhauled the highly successful BioTec 12 ScreenMatic filter and have released the innovative BioTec ScreenMatic² 40000 Pond Filter. This compact gravity outlet, flow-through filter box features an automated pre-filter conveyor which will screen out larger debris and transport this on a porous conveyor belt to a large collection basket for periodic emptying. The new Screendrive mechanism is now fully automated via a special cleaning sensor which controls the belt functions depending on the dirt level detected on the porous belt. Only small particles pass through the ScreenMatic drive belt where the large surface area biological/mechanical filter foams will trap and break down the organic waste. This innovative mechanism places far less biological load on the filter foams, meaning less maintenance and crystal clear water quality in ornamental, Goldfish and Koi ponds alike.
The OASE BioTec ScreenMatic² 40000 is an intelligent, flow-through pond filter that provides automated mechanical waste removal and biological filtration. The water enters the filter via a flow spreader onto a 300 micron fabric belt which strains out solid waste particles. When sufficiently soiled, a sensor engages the motor which performs a cleaning cycle, transferring the accumulated waste into a collection tray below the screen. The control display also allows instant cleaning cycles at the press of a button. The waste sensor can be adjusted backward and forward to alter cleaning regularity based on waste accumulation. A cleaning brush is supplied to keep the fabric screen free of entrapped dirt.
After mechanical straining, water enters the the biological media, a series of 8 large filter sponges differing in coarseness. The blue foams are rough, violet are medium fine and red are very fine grade. These sponges provide an abundance of surface housing for aerobic bacteria to populate and breakdown soluble waste pollutants. Cleaning the foams is made easy by the compression handle used to push down on the foams to release any build up of organic waste. Water is then directed through cartridges containing 3.5kg of granulate media (zeolite) which bind unwanted nutrients and trace ammonia before returning water to the pond.
- Incl. OASE Clear Water Guarantee
- Significantly less maintenance is required, thanks to coarse debris extraction
- More convenience, thanks to automatically driven self cleaning of the belt filter. Adjustable cleaning Sensor controls the belt run, depending on the degree of pollution. Incl. LED function check
- Cleaning of filter sponges directly in the filter, without removal
- Sludge drain with slide valve for removing debris from the filter system
- Different filter media for optimal development of filter bacteria
- Use of the PhosLess filter media tubes as needed for string algae reduction (optional accessory)
- Optimally matched to OASE AquaMax Eco filter pumps
- Direct connection possibility for Bitron C and Eco UVC clarifiers
- Reinforced strap material for an extended service life
- Double-sealed motor for an extended service life
- Water distributor without danger of clogging: Distributes the water uniformly on the belt filter
- Sludge basket with greater volume and simplified handling
- Rubberised separating lip for outstanding separation result
- Free brush for occasional cleaning of the belt filter
- Manual belt run now possible via button
- Highly effective flow-through filter for ponds up to 40.0 m³
Lids of models 40,000 and 60,000 with storm-safe fastening clips
| Dimensions (L x W x H) | mm | 788 x 590 x 445 |
|---|---|---|
| Rated voltage (primary, secondary) | 230 V / 50 Hz, 12 V / AC | |
| Power consumption | W | 5 |
| Cable length 12 V device (with power unit) | m | 2.10 (Power unit) + 5.00 |
| Net weight | kg | 20.00 |
| Guarantee | Years | 2 + 1 |
| Number of filter foams, total | Units | 8 |
| Number of blue filter foams | Units | 2 |
| Number of red filter foams | Units | 3 |
| Number of purple filter foams | Units | 3 |
| Special filter granulate | kg | 2.50 |
| Temperature display | No | |
| Coarse debris extraction | µm | 300 |
| Inlet connections | mm | 25 / 32 / 38 |
| Inlet connections | 1″, 1 ¼”, 1 ½” | |
| Outlet connections | DN 75 | |
| Sludge discharge connections | DN 50 | |
| Min. flow rate | l/h | 4000 |
| Max. flow rate | l/h | 9000 |
| Suitable for ponds up to max. | m³ | 40.0 |
| Suitable for ponds with fish stock | m³ | 20.0 |
| Suitable for ponds with koi stock | m³ | 10.0 |
| Connection to | Bitron C 36 – 110 W, Bitron Eco 120 – 240 W |
Oase Biotec Screenmatic2 60000
Oase Biotec Screenmatic2 60000
OASE German Engineers have completely overhauled the highly successful BioTec 18 ScreenMatic filter and have released the innovative BioTec ScreenMatic² 60000 Pond Filter. This compact gravity outlet, flow-through filter box features an automated pre-filter conveyor which will screen out larger debris and transport this on a porous conveyor belt to a large collection basket for periodic emptying. The new Screendrive mechanism is now fully automated via a special cleaning sensor which controls the belt functions depending on the dirt level detected on the porous belt. Only small particles pass through the ScreenMatic drive belt where the large surface area biological/mechanical filter foams will trap and break down the organic waste. This innovative mechanism places far less biological load on the filter foams, meaning less maintenance and crystal clear water quality in ornamental, Goldfish and Koi ponds alike.
The OASE BioTec ScreenMatic² 60000 is an intelligent, flow-through pond filter that provides automated mechanical waste removal and biological filtration. The water enters the filter via a flow spreader onto a 300 micron fabric belt which strains out solid waste particles. When sufficiently soiled, a sensor engages the motor which performs a cleaning cycle, transferring the accumulated waste into a collection tray below the screen. The control display also allows instant cleaning cycles at the press of a button. The waste sensor can be adjusted backward and forward to alter cleaning regularity based on waste accumulation. A cleaning brush is supplied to keep the fabric screen free of entrapped dirt.
After mechanical straining, water enters the the biological media, a series of 8 large filter sponges differing in coarseness. The blue foams are rough, violet are medium fine and red are very fine grade. These sponges provide an abundance of surface housing for aerobic bacteria to populate and breakdown soluble waste pollutants. Cleaning the foams is made easy by the compression handle used to push down on the foams to release any build up of organic waste. Water is then directed through cartridges containing 3.5kg of granulate media (zeolite) which bind unwanted nutrients and trace ammonia before returning water to the pond.
- Incl. OASE Clear Water Guarantee
- Significantly less maintenance is required, thanks to coarse debris extraction
- More convenience, thanks to automatically driven self cleaning of the belt filter. Adjustable cleaning Sensor controls the belt run, depending on the degree of pollution. Incl. LED function check
- Cleaning of filter sponges directly in the filter, without removal
- Sludge drain with slide valve for removing debris from the filter system
- Different filter media for optimal development of filter bacteria
- Use of the PhosLess filter media tubes as needed for string algae reduction (optional accessory)
- Optimally matched to OASE AquaMax Eco filter pumps
- Direct connection possibility for Bitron C and Eco UVC clarifiers
- Reinforced strap material for an extended service life
- Double-sealed motor for an extended service life
- Water distributor without danger of clogging: Distributes the water uniformly on the belt filter
- Sludge basket with greater volume and simplified handling
- Rubberised separating lip for outstanding separation result
- Free brush for occasional cleaning of the belt filter
- Manual belt run now possible via button
- Highly effective flow-through filter for ponds up to 60.0 m³
- Lids of models 40,000 and 60,000 with storm-safe fastening clips
| Dimensions (L x W x H) | mm | 788 x 590 x 545 |
|---|---|---|
| Rated voltage (primary, secondary) | 230 V / 50 Hz, 12 V / AC | |
| Power consumption | W | 5 |
| Cable length 12 V device (with power unit) | m | 2.10 (Power unit) + 5.00 |
| Net weight | kg | 23.50 |
| Guarantee | Years | 2 + 1 |
| Number of filter foams, total | Units | 8 |
| Number of blue filter foams | Units | 2 |
| Number of red filter foams | Units | 3 |
| Number of purple filter foams | Units | 3 |
| Special filter granulate | kg | 3.50 |
| Temperature display | No | |
| Coarse debris extraction | µm | 300 |
| Inlet connections | mm | 25 / 32 / 38 |
| Inlet connections | 1″, 1 ¼”, 1 ½” | |
| Outlet connections | DN 75 | |
| Sludge discharge connections | DN 50 | |
| Min. flow rate | l/h | 6000 |
| Max. flow rate | l/h | 11000 |
| Suitable for ponds up to max. | m³ | 60.0 |
| Suitable for ponds with fish stock | m³ | 30.0 |
| Suitable for ponds with koi stock | m³ | 15.0 |
| Connection to | Bitron C 36 – 110 W, Bitron Eco 120 – 240 W |
Oase Biotec Screenmatic2 90000
The OASE BioTec ScreenMatic² 90000 is an innovative auto-cleaning filtration system for both ornamental ponds and fish ponds alike. The filtration system operates using a rotating screen belt which intercepts solid waste upon entry and transfers this to a collection tray when filled. Waste levels are measured by a sensor bar which engages a cleaning cycle when the sieve screen belt is sufficiently filled with waste, the sensor bar position can be adjusted to suit the flow rate from different pumps and regulate the amount of waste intercepted before self-cleaning. Beneath the screen mechanism are a series of 16 filter sponges in 3 different grades of coarseness, these provide excellent biological filtration after the mechanical extraction, removing harmful soluble waste product. Water is also passed through Zeolite media in the front chamber which collects waste and nutrient in solution before water is returned to the pond.
The OASE BioTec ScreenMatic² 90000 is an intelligent, flow-through pond filter that provides automated mechanical waste removal and biological filtration. The water enters the filter via a flow spreader onto a 300 micron fabric belt which strains out solid waste particles. When sufficiently soiled, a sensor engages the motor which performs a cleaning cycle, transferring the accumulated waste into a collection tray below the screen. The control display also allows instant cleaning cycles at the press of a button. The waste sensor can be adjusted backward and forward to alter cleaning regularity based on waste accumulation. A cleaning brush is supplied to keep the fabric screen free of entrapped dirt.
After mechanical straining, water enters the the biological media, a series of 16 large filter sponges differing in coarseness. The blue foams are rough, violet are medium fine and red are very fine grade. These sponges provide an abundance of surface housing for aerobic bacteria to populate and breakdown soluble waste pollutants. Cleaning the foams is made easy by the compression handle used to push down on the foams to release any build up of organic waste. Water is then directed through cartridges containing 5kg of granulate media (zeolite) which bind unwanted nutrients and trace ammonia before returning water to the pond.
- Incl. OASE Clear Water Guarantee
- Significantly less maintenance is required, thanks to coarse debris extraction
- More convenience, thanks to automatically driven self cleaning of the belt filter. Adjustable cleaning Sensor controls the belt run, depending on the degree of pollution. Incl. LED function check
- Cleaning of filter sponges directly in the filter, without removal
- Sludge drain with slide valve for removing debris from the filter system
- Different filter media for optimal development of filter bacteria
- Use of the PhosLess filter media tubes as needed for string algae reduction (optional accessory)
- Optimally matched to OASE AquaMax Eco filter pumps
- Direct connection possibility for Bitron C and Eco UVC clarifiers
- Reinforced strap material for an extended service life
- Double-sealed motor for an extended service life
- Water distributor without danger of clogging: Distributes the water uniformly on the belt filter
- Sludge basket with greater volume and simplified handling
- Rubberised separating lip for outstanding separation result
- Free brush for occasional cleaning of the belt filter
- Manual belt run now possible via button
- Highly effective flow-through filter for ponds up to 90.0 m³
- Lids of models 40,000 and 60,000 with storm-safe fastening clips
-
Dimensions (L x W x H) mm 788 x 590 x 645 Rated voltage (primary, secondary) 230 V / 50 Hz, 12 V / AC Power consumption W 5 Cable length 12 V device (with power unit) m 2.10 (Power unit) + 5.00 Net weight kg 27.00 Guarantee Years 2 + 1 Number of filter foams, total Units 16 Number of blue filter foams Units 4 Number of red filter foams Units 6 Number of purple filter foams Units 6 Special filter granulate kg 5.00 Temperature display No Coarse debris extraction µm 300 Inlet connections mm 25 / 32 / 38 / 50 Inlet connections 1″, 1 ¼”, 1 ½”, 2″ Outlet connections DN 110 Sludge discharge connections DN 50 Min. flow rate l/h 8000 Max. flow rate l/h 12500 Suitable for ponds up to max. m³ 90.0 Suitable for ponds with fish stock m³ 45.0 Suitable for ponds with koi stock m³ 22.5 Connection to Bitron C 36 – 110 W, Bitron Eco 120 – 240 W
Oase Biotec Screenmatic2 Set 40000 OC
Oase Biotec Screenmatic2 Set 40000 OC
The Oase BioTec ScreenMatic² 40000 OC is a compact, low maintenance flow-through pond filter providing mechanical and biological filtration; creating crystal clear water quality in ornamental, Goldfish and Koi ponds alike. The Biotec Screenmatic² is a follow on from one of the most advanced and well sold filters in the Oase Biotec family. The ScreenMatic² filter is a combination of all the well known features of its predecessor as well as enhanced benefits that have been introduced to make this filter more efficient and even easier to operate then ever before.
The Oase BioTec ScreenMatic² Set 40000 OC consists of the BioTec ScreenMatic² 40000 Pond Filter, the AquaMax Eco Premium 13000 Pond Pump and the Bitron 36C UVC. This optimally matched pump, filter and UVC set provides crystal clear water for ponds up to 40,000 litres.
Set Includes:
- Oase Aquamax Eco Premium 13000 Pond Pump
- Oase Bitron 36C UVC
- Oase BioTec ScreenMatic² 40000 Pond Filter
- Oase BioKick Filter Starter
Oase Biotec Screenmatic2 Set 60000 OC
Oase Biotec Screenmatic2 Set 60000 OC
The Oase BioTec ScreenMatic² 60000 OC is a compact, low maintenance flow-through pond filter providing mechanical and biological filtration; creating crystal clear water quality in ornamental, Goldfish and Koi ponds alike. The Biotec Screenmatic² is a follow on from one of the most advanced and well sold filters in the Oase Biotec family. The ScreenMatic² filter is a combination of all the well known features of its predecessor as well as enhanced benefits that have been introduced to make this filter more efficient and even easier to operate then ever before.
The Oase BioTec ScreenMatic² Set 60000 OC consists of the BioTec ScreenMatic² 60000 Pond Filter, the Aqua Max Eco Premium 17000 Pond Pump and the Bitron 55C UVC. This optimally matched pump, filter and UVC set provides crystal clear water for ponds up to 60,000 litres.
Set Includes:
- Oase Aquamax Eco Premium 17000 Pond Pump
- Oase Bitron 55C UVC
- Oase BioTec ScreenMatic² 60000 Pond Filter
- Oase BioKick Filter Starter
Oase Biotec Screenmatic2 Set 90000 OC
Oase Biotec Screenmatic2 Set 90000 OC
The Oase BioTec ScreenMatic² 90000 OC is a compact, low maintenance flow-through pond filter providing mechanical and biological filtration; creating crystal clear water quality in ornamental, Goldfish and Koi ponds alike. The Biotec Screenmatic² is a follow on from one of the most advanced and well sold filters in the Oase Biotec family. The ScreenMatic² filter is a combination of all the well known features of its predecessor as well as enhanced benefits that have been introduced to make this filter more efficient and even easier to operate then ever before.
The Oase BioTec ScreenMatic² Set 90000 OC consists of the BioTec ScreenMatic² 90000 Pond Filter, the Aqua Max Eco Premium 21000 Pond Pump and the Bitron 110C UVC. This optimally matched pump, filter and UVC set provides crystal clear water for ponds up to 90,000 litres.
Set Includes:
- Oase Aquamax Eco Premium 21000 Pond Pump
- Oase Bitron 110C UVC
- Oase BioTec ScreenMatic² 90000 Pond Filter
- Oase BioKick Filter Starter
Oase Compact-L Drum filter kit
Oase Compact-L Drum filter kit
At Cotswold koi We understand that sometimes it can be confusing as to knowing what equipment you require for your pond, So we have put together this kit which will make your life a 100% easier.
System spec:
4″ single Spin Drifter Aerated Bottom Drain and pipework and 4″ball valve
4″ wall skimmer and pipework and 4″ball valve
Both these would feed back to the Oase Compact-L Drum filter
Hi Blow XP 40 Air Pump to power the Aerated SpinDrifter drain
Hi Blow XP 40 Air Pump to Aerate the Oase Compact-L bio chamber
we’ve gone for two Evolution Aqua Vari pump 10000’s (dual pumps build redundancy into the system)
please see individual items for more information click the links below.
you can adjust the quantity so suit your project SpinDrifter Aerated Bottom Drain
Oase Compact-L Drum filter kit (Colin)
Draco Medius Drum filter kit
At Cotswold koi We understand that sometimes it can be confusing as to knowing what equipment you require for your pond, So we have put together this kit which will make your life a 100% easier.
System spec:
4″ single Spin Drifter Aerated Bottom Drain and pipework and 4″ball valve
4″ wall skimmer and pipework and 4″ball valve
Both these would feed back to the Draco Drum Medius Combi unit
Hi Blow XP 40 Air Pump to power the Aerated SpinDrifter drain
Hi Blow XP 80 Air Pump to Aerate the Draco Medius bio chamber
we’ve gone for two Evolution Aqua Vari pump 10000’s (dual pumps build redundancy into the system)
please see individual items for more information click the links below.
you can adjust the quantity so suit your project SpinDrifter Aerated Bottom Drain
Oase Compact-L Drum filter kit 3″ drains (josh)
Oase Compact-L Drum filter kit
At Cotswold koi we understand that sometimes it can be confusing to know what equipment you require for your pond, So we have put together this useful Oase Compact-L Drum filter kit which will make your life a 100% easier.
The kit includes everything you need to get your filter up and running and you can even customise each item to suit your own individual project.
System spec:
- 3″” multi Spin Drifter Aerated Bottom Drain and pipework and 3″ ball valve.
- 4″ wall skimmer with 3″ pipework and 3″ ball valve.
- Both these would feedback to the Drum filter.
- Hi Blow 100 Air Pump to power the Aerated SpinDrifter drains.
- Hi Blow 40 Air Pump to Aerate the bio chamber.
We’ve decided to include with the Oase Compact-L Drum kit, two Evolution Aqua Vari pump 10000’s (dual pumps build redundancy into the system).
Please see individual items for more information click the links below.
You can also adjust the quantity of each included item to suit your project.
Do you require assistance with this filter kit? Get in touch today and we’ll be happy to help.
Looking for other pond filters? Check out our full range. Click here!
Oase Drum filter kit for up to 45,000
Oase Drum filter kit for upto 45,000
At Cotswold koi We understand that sometimes it can be confusing as to knowing what equipment you require for your pond, So we have put together this kit which will make your life a 100% easier.
System spec:
2x 4″ Spin Drifter Aerated Bottom Drain and pipework and 4″ball valve
1x 4″ wall skimmer and pipework and 4″ball valve
These would feed back to the Oase ProfiClear Premium DF-L gravity-fed EGC Drum Filter
and then on into the Oase ProfiClear Premium Moving Bed Modules
and then finally into the Oase ProfiClear Premium Individual Module
where the 2x AquaMax Eco Gravity 15000’s (dual pumps build redundancy into the system)
and the 2x Oase Bitron Premium 60 W UV’s are located.
2x Hi Blow XP 40 Air Pump to power the Aerated SpinDrifter drains
2x Hi Blow XP 40 Air Pump to Aerate the Oase ProfiClear Premium Moving Bed Modules
we have added the flexible adapters and 2″ return pipe work
please see individual items for more information click the links below.
you can adjust the quantity so suit your project
Oase Filtoclear 13000
Oase Filtoclear 13000
The Oase Filtoclear Pond Filters are a highly developed range of pressure filters designed with ease of use and quality filtration in mind.
Pond water is pumped into a sealed filter unit creating a pressure of up to 0.2 bar. This in turn means that water leaves the filter under pressure, allowing the water to be pushed up to a waterfall, unlike a conventional gravity return filter, which must always be positioned at the highest point of the system.
The Filtoclear pressure filter also has been designed with all the connections and major operating elements in the lid allowing the filter to be partly buried out of sight
Oase has always created high-quality solutions for natural-looking water gardens. FiltoClear is one of the cornerstones of our pond solutions. Now we are taking the pressure filter to a completely new level of quality:
Features:
- Four clearly defined models for pond sizes with a volume of water ranging from 5000 to 31,000 litres – with and without fish stock
- New pull-out mechanism that allows filter sponges to be conveniently cleaned without having to get dirty or disassemble the whole filter
- UVC housing with increased UV performance and simple lamp replacement while the filter is running
- UV cleaning rotor automatically cleans the quartz glass surrounding the UVC lamp – from FiltoClear 19000 onwards
- OASE Bypass technology ensures constant water flow and prevents clogging
- Three filter foams (instead of the two previously) for even more thorough cleaning – from FiltoClear 13000 onwards
- New clamping ring to make opening and closing the filter even easier
- Robust construction and materials ensure long service life
Oase Filtoclear 19000
Oase Filtoclear 19000
The Oase Filtoclear Pond Filters are a highly developed range of pressure filters designed with ease of use and quality filtration in mind.
Pond water is pumped into a sealed filter unit creating a pressure of up to 0.2 bar. This in turn means that water leaves the filter under pressure, allowing the water to be pushed up to a waterfall, unlike a conventional gravity return filter, which must always be positioned at the highest point of the system.
The Filtoclear pressure filter also has been designed with all the connections and major operating elements in the lid allowing the filter to be partly buried out of sight
Oase has always created high-quality solutions for natural-looking water gardens. FiltoClear is one of the cornerstones of our pond solutions. Now we are taking the pressure filter to a completely new level of quality:
Features:
- Four clearly defined models for pond sizes with a volume of water ranging from 5000 to 31,000 litres – with and without fish stock
- New pull-out mechanism that allows filter sponges to be conveniently cleaned without having to get dirty or disassemble the whole filter
- UVC housing with increased UV performance and simple lamp replacement while the filter is running
- UV cleaning rotor automatically cleans the quartz glass surrounding the UVC lamp – from FiltoClear 19000 onwards
- OASE Bypass technology ensures constant water flow and prevents clogging
- Three filter foams (instead of the two previously) for even more thorough cleaning – from FiltoClear 13000 onwards
- New clamping ring to make opening and closing the filter even easier
- Robust construction and materials ensure long service life
Oase Filtoclear 31000
Oase Filtoclear 31000
The Oase Filtoclear Pond Filters are a highly developed range of pressure filters designed with ease of use and quality filtration in mind.
Pond water is pumped into a sealed filter unit creating a pressure of up to 0.2 bar. This in turn means that water leaves the filter under pressure, allowing the water to be pushed up to a waterfall, unlike a conventional gravity return filter, which must always be positioned at the highest point of the system.
The Filtoclear pressure filter also has been designed with all the connections and major operating elements in the lid allowing the filter to be partly buried out of sight
Oase has always created high-quality solutions for natural-looking water gardens. FiltoClear is one of the cornerstones of our pond solutions. Now we are taking the pressure filter to a completely new level of quality:
Features:
- Four clearly defined models for pond sizes with a volume of water ranging from 5000 to 31,000 litres – with and without fish stock
- New pull-out mechanism that allows filter sponges to be conveniently cleaned without having to get dirty or disassemble the whole filter
- UVC housing with increased UV performance and simple lamp replacement while the filter is running
- UV cleaning rotor automatically cleans the quartz glass surrounding the UVC lamp – from FiltoClear 19000 onwards
- OASE Bypass technology ensures constant water flow and prevents clogging
- Three filter foams (instead of the two previously) for even more thorough cleaning – from FiltoClear 13000 onwards
- New clamping ring to make opening and closing the filter even easier
- Robust construction and materials ensure long service life
Oase Filtoclear 5000
Oase Filtoclear 5000
The Oase Filtoclear Pond Filters are a highly developed range of pressure filters designed with ease of use and quality filtration in mind.
Pond water is pumped into a sealed filter unit creating a pressure of up to 0.2 bar. This in turn means that water leaves the filter under pressure, allowing the water to be pushed up to a waterfall, unlike a conventional gravity return filter, which must always be positioned at the highest point of the system.
The Filtoclear pressure filter also has been designed with all the connections and major operating elements in the lid allowing the filter to be partly buried out of sight
Oase has always created high-quality solutions for natural-looking water gardens. FiltoClear is one of the cornerstones of our pond solutions. Now we are taking the pressure filter to a completely new level of quality:
Features:
- Four clearly defined models for pond sizes with a volume of water ranging from 5000 to 31,000 litres – with and without fish stock
- New pull-out mechanism that allows filter sponges to be conveniently cleaned without having to get dirty or disassemble the whole filter
- UVC housing with increased UV performance and simple lamp replacement while the filter is running
- UV cleaning rotor automatically cleans the quartz glass surrounding the UVC lamp – from FiltoClear 19000 onwards
- OASE Bypass technology ensures constant water flow and prevents clogging
- Three filter foams (instead of the two previously) for even more thorough cleaning – from FiltoClear 13000 onwards
- New clamping ring to make opening and closing the filter even easier
- Robust construction and materials ensure long service life
Oase Filtoclear Set 13000 OC
Oase Filtoclear Set 13000 OC
The Oase FiltoClear Set 13000 OC includes the Oase FiltoClear 13000 Pressure Filter with integrated 24w UVC and the new generation of ‘next level efficiency’ Oase AquaMax Eco Premium 9000 Filter Pump. The optimally matched pump and filter set create crystal clear ponds up to 13,000 litres without fish stock
The Oase Filtoclear Pond Filters are a highly developed range of pressure filters designed with ease of use and quality filtration in mind.
Pond water is pumped into a sealed filter unit creating a pressure of up to 0.2 bar. This in turn means that water leaves the filter under pressure, allowing the water to be pushed up to a waterfall, unlike a conventional gravity return filter, which must always be positioned at the highest point of the system.
The Filtoclear pressure filter also has been designed with all the connections and major operating elements in the lid allowing the filter to be partly buried out of sight
Oase has always created high-quality solutions for natural-looking water gardens. FiltoClear is one of the cornerstones of our pond solutions. Now we are taking the pressure filter to a completely new level of quality:
The new OC filter sets allow integration into the Oase Control System using an Oase Garden Controller Cloud or Oase InScenio FM-Master Cloud along with Oase Control Cables (available separately). Then Simply download the Oase Control app (from the App Store or via Play Store) – and off you go.
Features:
- Four clearly defined models for pond sizes with a volume of water ranging from 5000 to 31,000 litres – with and without fish stock
- New pull-out mechanism that allows filter sponges to be conveniently cleaned without having to get dirty or disassemble the whole filter
- UVC housing with increased UV performance and simple lamp replacement while the filter is running
- UV cleaning rotor automatically cleans the quartz glass surrounding the UVC lamp – from FiltoClear 19000 onwards
- OASE Bypass technology ensures constant water flow and prevents clogging
- Three filter foams (instead of the two previously) for even more thorough cleaning – from FiltoClear 13000 onwards
- New clamping ring to make opening and closing the filter even easier
- Robust construction and materials ensure long service life
Includes AquaMax Eco Premium 9000 OC Pump
Oase Filtoclear Set 19000 OC
Oase Filtoclear Set 19000 OC
The Oase FiltoClear Set 19000 OC includes the Oase FiltoClear 19000 Pressure Filter with integrated 18w UVC and the new generation of ‘next level efficiency’ Oase AquaMax Eco Premium 13000 Filter Pump. The optimally matched pump and filter set create crystal clear ponds up to 19,000 litres without fish stock
The Oase Filtoclear Pond Filters are a highly developed range of pressure filters designed with ease of use and quality filtration in mind.
Pond water is pumped into a sealed filter unit creating a pressure of up to 0.2 bar. This in turn means that water leaves the filter under pressure, allowing the water to be pushed up to a waterfall, unlike a conventional gravity return filter, which must always be positioned at the highest point of the system.
The Filtoclear pressure filter also has been designed with all the connections and major operating elements in the lid allowing the filter to be partly buried out of sight
Oase has always created high-quality solutions for natural-looking water gardens. FiltoClear is one of the cornerstones of our pond solutions. Now we are taking the pressure filter to a completely new level of quality:
The new OC filter sets allow integration into the Oase Control System using an Oase Garden Controller Cloud or Oase InScenio FM-Master Cloud along with Oase Control Cables (available separately). Then Simply download the Oase Control app (from the App Store or via Play Store) – and off you go.
Features:
- Four clearly defined models for pond sizes with a volume of water ranging from 5000 to 31,000 litres – with and without fish stock
- New pull-out mechanism that allows filter sponges to be conveniently cleaned without having to get dirty or disassemble the whole filter
- UVC housing with increased UV performance and simple lamp replacement while the filter is running
- UV cleaning rotor automatically cleans the quartz glass surrounding the UVC lamp – from FiltoClear 19000 onwards
- OASE Bypass technology ensures constant water flow and prevents clogging
- Three filter foams (instead of the two previously) for even more thorough cleaning – from FiltoClear 13000 onwards
- New clamping ring to make opening and closing the filter even easier
- Robust construction and materials ensure long service life
Includes AquaMax Eco Premium 13000 OC Pump
Oase Filtoclear Set 31000 OC
Oase Filtoclear Set 31000 OC
The Oase FiltoClear Set 31000 OC includes the Oase FiltoClear 31000 Pressure Filter with integrated 60w UVC and the new generation of ‘next level efficiency’ Oase AquaMax Eco Premium 17000 Filter Pump. The optimally matched pump and filter set create crystal clear ponds up to 31,000 litres without fish stock
The Oase Filtoclear Pond Filters are a highly developed range of pressure filters designed with ease of use and quality filtration in mind.
Pond water is pumped into a sealed filter unit creating a pressure of up to 0.2 bar. This in turn means that water leaves the filter under pressure, allowing the water to be pushed up to a waterfall, unlike a conventional gravity return filter, which must always be positioned at the highest point of the system.
The Filtoclear pressure filter also has been designed with all the connections and major operating elements in the lid allowing the filter to be partly buried out of sight
Oase has always created high-quality solutions for natural-looking water gardens. FiltoClear is one of the cornerstones of our pond solutions. Now we are taking the pressure filter to a completely new level of quality:
The new OC filter sets allow integration into the Oase Control System using an Oase Garden Controller Cloud or Oase InScenio FM-Master Cloud along with Oase Control Cables (available separately). Then Simply download the Oase Control app (from the App Store or via Play Store) – and off you go.
Features:
- Four clearly defined models for pond sizes with a volume of water ranging from 5000 to 31,000 litres – with and without fish stock
- New pull-out mechanism that allows filter sponges to be conveniently cleaned without having to get dirty or disassemble the whole filter
- UVC housing with increased UV performance and simple lamp replacement while the filter is running
- UV cleaning rotor automatically cleans the quartz glass surrounding the UVC lamp – from FiltoClear 19000 onwards
- OASE Bypass technology ensures constant water flow and prevents clogging
- Three filter foams (instead of the two previously) for even more thorough cleaning – from FiltoClear 13000 onwards
- New clamping ring to make opening and closing the filter even easier
- Robust construction and materials ensure long service life
Includes AquaMax Eco Premium 17000 OC pump
Oase Filtoclear Set 5000 OC
Oase Filtoclear Set 5000 OC
The Oase FiltoClear Set 5000 OC includes the Oase FiltoClear 5000 Pressure Filter with integrated 18w UVC and the new generation of ‘next level efficiency’ Oase AquaMax Eco Premium 5000 Filter Pump. The optimally matched pump and filter set create crystal clear ponds up to 5,000 litres without fish stock
The Oase Filtoclear Pond Filters are a highly developed range of pressure filters designed with ease of use and quality filtration in mind.
Pond water is pumped into a sealed filter unit creating a pressure of up to 0.2 bar. This in turn means that water leaves the filter under pressure, allowing the water to be pushed up to a waterfall, unlike a conventional gravity return filter, which must always be positioned at the highest point of the system.
The Filtoclear pressure filter also has been designed with all the connections and major operating elements in the lid allowing the filter to be partly buried out of sight
Oase has always created high-quality solutions for natural-looking water gardens. FiltoClear is one of the cornerstones of our pond solutions. Now we are taking the pressure filter to a completely new level of quality:
The new OC filter sets allow integration into the Oase Control System using an Oase Garden Controller Cloud or Oase InScenio FM-Master Cloud along with Oase Control Cables (available separately). Then Simply download the Oase Control app (from the App Store or via Play Store) – and off you go.
Features:
- Four clearly defined models for pond sizes with a volume of water ranging from 5000 to 31,000 litres – with and without fish stock
- New pull-out mechanism that allows filter sponges to be conveniently cleaned without having to get dirty or disassemble the whole filter
- UVC housing with increased UV performance and simple lamp replacement while the filter is running
- UV cleaning rotor automatically cleans the quartz glass surrounding the UVC lamp – from FiltoClear 19000 onwards
- OASE Bypass technology ensures constant water flow and prevents clogging
- Three filter foams (instead of the two previously) for even more thorough cleaning – from FiltoClear 13000 onwards
- New clamping ring to make opening and closing the filter even easier
- Robust construction and materials ensure long service life
Includes AquaMax Eco Premium 5000 OC Pump
Oase Filtomatic 14000 CWS
Oase Filtomatic 14000 CWS
Enjoy your pond – your pond manager FiltoMatic CWS 14000 does the work. This intelligent pond filter not only cleans ponds up to 14 m³, with fish up to 7 m³, but also gets rid of its own dirt inside. Thanks to the permanent temperature measurement of the water, the control unit starts the integrated 24 watt UVC clarifier with its patented cleaning function independently and as required, thus enabling electricity savings of up to 40%. The intelligence pays off. The control unit also automatically activates the sludge pump, which conveys the dirt out of the filter. This also reduces the growth of thread algae through permanent nutrient discharge. Cleaning the outside of the filter sponges is almost as easy and clean – without getting your hands dirty.
- Up to 40% power savings thanks to UVC unit that is activated as needed (as compared to devices without power saving function in continuous operation)
- Virtually invisible, the filter device can be buried to 70 % of the device height
- Low maintenance and user friendly
Oase Filtomatic 25000 CWS
Oase Filtomatic 25000 CWS
Enjoy your pond – your pond manager FiltoMatic CWS 25000 does the work. This intelligent pond filter not only cleans ponds up to 25 m³, with fish up to 12.5 m³, but also gets rid of its own dirt inside. Thanks to the permanent temperature measurement of the water, the control unit starts the integrated 24 watt UVC clarifier with reflector technology and its patented cleaning function independently and as required. This enables electricity savings of up to 40%. The intelligence pays off. The control unit also automatically activates the sludge pump, which conveys the dirt out of the filter. This also reduces the growth of thread algae through permanent nutrient discharge. Cleaning the outside of the filter sponges is almost as easy and clean – without getting your hands dirty. Trust in OASE quality, because you receive a total of up to 3 years guarantee – 2 plus 1 year requirement guarantee as well as the OASE clear water guarantee.
- Up to 40% power savings thanks to UVC unit that is activated as needed (as compared to devices without power saving function in continuous operation)
- Virtually invisible, the filter device can be buried to 70 % of the device height
- Low maintenance and user friendly
Oase Filtomatic 7000 CWS
Oase Filtomatic 7000 CWS
Enjoy your pond – your pond manager FiltoMatic CWS 7000 does the work. This intelligent pond filter not only cleans ponds up to 7 m³, with fish up to 3.5 m³, but also gets rid of its own dirt inside. Thanks to the permanent temperature measurement of the water, the control unit starts the integrated 11 watt UVC clarifier with its patented cleaning function independently and as required, thus enabling electricity savings of up to 40%. The intelligence pays off. The control unit also automatically activates the sludge pump, which conveys the dirt out of the filter. This also reduces the growth of thread algae through permanent nutrient discharge. Cleaning the outside of the filter sponges is almost as easy and clean – without getting your hands dirty.
- Up to 40% power savings thanks to UVC unit that is activated as needed (as compared to devices without power saving function in continuous operation)
- Virtually invisible, the filter device can be buried to 70 % of the device height
- Low maintenance and user friendly
Oase InScenio EGC Cloud
Oase InScenio EGC Cloud
The Oase InScenio EGC Controller is used to bring wireless remote monitoring and control a range of Oase Easy Garden Control (EGC) compatible products . The EGC controller can be centrally installed within your garden allowing connection to up to 10 EGC compatible products (daisy-linked) using EGC connection cable. The controller is fully weatherproof and can be installed up to 80m (with an unobstructed 2.4GHz wifi signal) from you home wifi router.
Characteristics:
- Globally accessible free-of-charge via the OASE Cloud
- Innovative controller for networking the OASE EGC devices, can be controlled via WiFi with tablet or smart phone (iOS or Android)
- Simply download the app (from the Apple Store or via Google Play), connect EGC devices and get started
- Up to 10 EGC-capable OASE devices (pumps, filters, light) can be connected and controlled
- All-season outdoor use thanks to splash-proof housing
- With flexible fastening material for fixing on a ground stake or for wall installation (included in the scope of delivery)
- System requirements: iOS 12.0 (Apple) or Android version 7.0 or later is required to run the app on mobile devices.
- Cloud compatible: Accessible worldwide via the free OASE cloud (InScenio Controller Cloud)
- Oase control: Up to 10 OASE-controlled terminals (pumps, filters, light) can be connected, controlled and monitored
- All year round: The housing is protected against splashing water (IP68) and can be operated outdoors all year round
- Included: Flexible mounting material for wall mounting or peg mounting included in the set
- App compatible: Simply download the OASE Control app (from the App Store or via Google Play) and you’re ready to go
Oase ProfiClear Premium Compact-L Gravity
ProfiClear Premium Compact-L gravity
This new compact drum filter of the ProfiClear Premium series is the inexpensive alternative for small to medium-sized bodies of water. The compact modular filter system is particularly ideal for koi ponds up to 35 m³. Leading koi experts were consulted in developing the range. In the gravitation principle, the maximum water flow through the filter is 25,000 liters per hour. With this completely self-cleaning drum filter unit, the moving bed system ensures optimal water movement and cleaning. Professional Hel-X bacteria cause the effective breakdown of nutrients and pollutants in the water. A depth filtration of up to 60 microns and a new Hel-X 13 filter medium with a significantly larger surface ensure the high separation efficiency.
Characteristics
- Professional compact drum filter as inexpensive alternative for smaller ponds, particularly koi ponds
- High separation performance in the pump-fed as well as gravity-fed principle
- Minimal space requirements and effective integration
- Conveniently control all settings via an app with the Easy Garden Control System (EGC); existing systems can be upgraded using the separately available upgrade kit
Oase ProfiClear Premium Compact-L Pump Fed Drum Filter EGC
Oase ProfiClear Premium Compact-L Pump Fed Drum Filter EGC
This new compact drum filter of the ProfiClear Premium series is the inexpensive alternative for small to medium-sized bodies of water. The compact modular filter system is ideal for koi ponds up to 30 m³ in particular. Leading koi experts were consulted in developing the range. In the pumped principle, the maximum water flow through the filter is 20,000 liters per hour. With this completely self-cleaning drum filter unit, the moving bed system ensures optimal water movement and cleaning. Professional Hel-X bio-media effectively break down nutrients and pollutants in the water. A depth filtration of up to 60 microns and a new Hel-X 13 filter medium with a significantly larger surface ensure the high separation efficiency.
Features:
- High Separation Capacity through deep bed filtration up to 60 microns.
- Hel-X 13 filter media with a significantly enlarged surface area for effective decomposition of nutrients and pollutants.
- Large drum with micron 60 meshes and auto clean feature.
- Large fluidised moving bed section for maximum decomposition of pollutants.
- Can be used with the EGC Control unit.
- Auto Clean Feature.
- Control unit with digital display and temperature display.
Oase ProfiClear Premium Compact-M Gravity Filter kit
Oase ProfiClear Premium Compact-M Gravity Filter kit
At Cotswold koi We understand that sometimes it can be confusing as to knowing what equipment you require for your pond, So we have put together this kit which will make your life a 100% easier.
System spec:
4″ single Spin Drifter Aerated Bottom Drain and pipework and 4″ball valve
4″ wall skimmer and pipework and 4″ball valve
Both these would feed back to the Compact-M Gravity Combi unit
Hi Blow XP 40 Air Pump to power the Aerated SpinDrifter drain
Hi Blow XP 40 Air Pump to Aerate the Compact-M Gravity Combi unit
we’ve gone for a AquaMax Eco Gravity 15000 for the circulation pump
please see individual items for more information click the links below.
you can adjust the quantity so suit your project
Oase ProfiClear Premium Compact-M Gravity EGC
Oase ProfiClear Premium Compact-M Gravity
The Oase ProfiClear Premium Compact-M is a self-cleaning gravity fed drum filter, offering an inexpensive alternative for smaller ponds up to 80,000 Litres.
With the inner moving bed system, the Hel-X 13 filter media provides optimal water movement and cleaning of the water and its significantly enlarged surface area offers effective decomposition of nutrients and pollutants.
This is an excellent drum filter unit that naturally integrates into the landscape even in areas where space is limited.
Product Features:
- Suitable for Ponds up to 80m3
- Innovative New Drum Filter for Smaller Ponds and Koi
- High Separation Performance with Gravity Fed Technology
- Self Cleaning Functionality
- Moving Bed System for Optimal Water Cleaning
- Hel-X 13 Filter Media Offers Effective Decomposition of Pollutants
- Can Be Easily Combined with a Bitron Gravity UVC Clarifier
Please Note: Imagery may show optional accessories not included as standard.
https://youtu.be/5j6Cgf72K08
Oase ProfiClear Premium Compact-M Pumped EGC
Oase ProfiClear Premium Compact-M
Oase ProfiClear Premium Compact-M is a compact and self-cleaning pumped drum filter which offers an inexpensive alternative for smaller ponds up to 80,000 Litres.
With the inner moving bed system, the Hel-X 13 filter media provides optimal water movement and cleaning of the water and its significantly enlarged surface area offers effective decomposition of nutrients and pollutants.
This is an excellent drum filter unit that naturally integrates into the landscape even in areas where space is limited.
Product Features:
- Suitable for Ponds up to 80m3
- Innovative New Drum Filter for Smaller Ponds and Koi
- High Separation Performance with Pump Fed Technology
- Self Cleaning Functionality
- Moving Bed System for Optimal Water Cleaning
- Hel-X 13 Filter Media Offers Effective Decomposition of Pollutants
- Can Be Easily Combined with a Bitron Gravity UVC Clarifiers
https://youtu.be/5j6Cgf72K08
Oase ProfiClear Premium DF-L gravity-fed EGC Drum Filter
Oase ProfiClear Premium DF-L gravity-fed EGC Drum Filter
With the ProfiClear Premium you get professional technology through the gravity-fed rotating Drum Filter that accepts flow rates up to 33,000 litres per hour.
This filter by Oase introduces over three years of development; the drum filter module provides deep bed filtration to 60 microns and the moving bed module contains Hel-X biomedia for intelligent decomposition of pollutants and nutrients.
This outstanding, high performance filter also has a sophisticated plug & play microcontroller which digitally displays the pond water temperature and handles the self cleaning function for unique, maintenance free operation.
*Suitable for Ponds 200000 litres, fish ponds 100000 ltitres and Koi 45000 litres.
Product Features:
- Automatic self cleaning
- Deep bed filtration to 60 microns
- First class price/performance ratio
- Safety cut-out switch is mounted to the filter lid
- Professional filter media and moving bed process
- GRP Duroplast / stainless steel material gives the filter drum an extremely stable and durable housing.
Oase ProfiClear Premium Individual Module
Oase ProfiClear Premium Individual Module Filter
The Oase ProfiClear Premium Individual Module Filter is ideal for both professional and new pond keepers too, giving you the best water quality possible through sophisticated technology.
Premium Gravity filters are modular in design, meaning they can be connected together in separate ways in order to create a tailored system to suit virtually any pond size.
The Individual Module allows for easy installation of Aquamax Gravity Eco filter pumps or Bitron Gravity UVC products.
Pre-installed within the Filter box are stainless steel baskets for addition extra filter materials from A (active carbon) to Z (Zeolite).
DN100 pipework allows for multiple installation configurations to suit your needs with minimal pressure loss.
3-year Guarantee after registering your item with Oase.
ProfiClear Individual Module Features:
Max Flow Rate of up to 25,000 Litres Per Hour
Minimum Flow Rate of 10,000 Litres Per Hour
Includes 2x 8 Litre Stainless Steel Baskets for Filter Material
Typically used as part of a Pumping or Gravity Fed System
