Draco Drum Bio Unit
Draco Drum Bio Unit was designed to co-ordinate with the Draco Drum Solum Range of drum filters, they utilise the same curved base configuration to reduce dirt traps and can be installed either singly or in multiples.
Advantages with the Draco Drum Bio Unit:
- The Design also causes the bio media to more easily circulate, thereby increasing the amount of bio media your water touches as it travels through the unit.
- Can be installed in multiple configurations to make best use of the space you have available.
- Standard models utilise Twin 4” inlet / 2″ outlets but can be modified for individual needs.
- 3/4″ Ball valve drain
- Dimensions – 610mm wide x 700mm long x 680mm depth.
- Holds 100 litres of typical bio media in 185 litres of water.
- One unit capable of filtering ponds of approx. 4,000 UK gallons per unit.
https://youtu.be/eF0NysVPjz8
How does the Draco Drum Bio Unit work?
Operation of the Draco Drum Bio Unit
Draco Drum Bio Unit unit is configured as a downward flow, diverted input unit with longitudinal air delivery, to manage water flow around the chamber, maximising the active volume for bio filtration.
Incoming water at the top will have a tendency to “track” diagonally or straight down to the outlet, the path of “least resistance”. By making it interact with the air from the bottom of the tank, this waterflow is disrupted and forced back upwards.
If part of the incoming flow is diverted towards the centre of the tank, the water is forced into the area where the air is rising, enhancing this flow disruption and pushing the water out to the sides.
As the water is pushed sideways at the surface of the unit, it has no choice but to travel downwards when it hits the side. The bottom of the chamber is curved, helping that downward flow turn into a circulatory movement. When reaching the airbar right at the bottom of the unit, the water is forced back up to repeat the circulation until it exists out of the far end. This curved bottom also eliminates any corners where debris may accumulate.
Draco Drum large Bio Unit
Draco Drum large Bio Unit was designed to co-ordinate with the Draco Drum Solum Range of drum filters, they utilise the same curved base configuration to reduce dirt traps and can be installed either singly or in multiples.
Advantages with the Draco Drum large Bio Unit:
- The Design also causes the bio media to more easily circulate, thereby increasing the amount of bio media your water touches as it travels through the unit.
- Can be installed in multiple configurations to make best use of the space you have available.
- Triple 4″ inlets / twin 2″ outlets but can be modified for individual needs.
- 1.5″ Ball valve drain
- Dimensions – 740mm wide x 1140mm long x 840mm depth.
- Holds 300 litres of typical bio media and half a tonne of water.
- Double central air line.
- One unit capable of filtering ponds of approx. 10,000 UK gallons.
How does the Draco Drum large Bio Unit work?
Operation of the Draco Drum large Bio Unit
Draco Drum large Bio Unit unit is configured as a downward flow, diverted input unit with longitudinal air delivery, to manage water flow around the chamber, maximising the active volume for bio filtration.
Incoming water at the top will have a tendency to “track” diagonally or straight down to the outlet, the path of “least resistance”. By making it interact with the air from the bottom of the tank, this waterflow is disrupted and forced back upwards.
If part of the incoming flow is diverted towards the centre of the tank, the water is forced into the area where the air is rising, enhancing this flow disruption and pushing the water out to the sides.
As the water is pushed sideways at the surface of the unit, it has no choice but to travel downwards when it hits the side. The bottom of the chamber is curved, helping that downward flow turn into a circulatory movement. When reaching the airbar right at the bottom of the unit, the water is forced back up to repeat the circulation until it exists out of the far end. This curved bottom also eliminates any corners where debris may accumulate.
Draco Drum midi Bio Unit
Draco Drum midi Bio Unit was designed to co-ordinate with the Draco Drum Solum Range of drum filters, they utilise the same curved base configuration to reduce dirt traps and can be installed either singly or in multiples.
Advantages with the Draco Drum Bio Unit:
- The Design also causes the bio media to more easily circulate, thereby increasing the amount of bio media your water touches as it travels through the unit.
- Can be installed in multiple configurations to make best use of the space you have available.
- Twin 4” inlet / 2″ outlets but can be modified for individual needs.
- Dimensions – 610mm wide x 1000mm long x 705mm depth.
- Holds 200 litres of typical bio media in 300 litres of water.
- One unit capable of filtering ponds of approx. 6,000 UK gallons.
https://youtu.be/XGQjCRHyLHk
How does the Draco Drum midi Bio Unit work?
Operation of the Draco Drum Midi Bio Unit
Draco Drum midi Bio Unit unit is configured as a downward flow, diverted input unit with longitudinal air delivery, to manage water flow around the chamber, maximising the active volume for bio filtration.
Incoming water at the top will have a tendency to “track” diagonally or straight down to the outlet, the path of “least resistance”. By making it interact with the air from the bottom of the tank, this waterflow is disrupted and forced back upwards.
If part of the incoming flow is diverted towards the centre of the tank, the water is forced into the area where the air is rising, enhancing this flow disruption and pushing the water out to the sides.
As the water is pushed sideways at the surface of the unit, it has no choice but to travel downwards when it hits the side. The bottom of the chamber is curved, helping that downward flow turn into a circulatory movement. When reaching the airbar right at the bottom of the unit, the water is forced back up to repeat the circulation until it exists out of the far end. This curved bottom also eliminates any corners where debris may accumulate.
Draco Drum Minima Combi Unit
The Minima – Combi Unit
Another first for Draco – a true, fully functional, expandable drum combi system for under £1200.
Perfect for quarantines, average stocked ponds to 2000 gallons, multi tank / sump installations and anywhere else a complete, compact unit is needed where there is very little space as it is only 30.5cm wide.
Height above static pond water level is 17.5cm .
This unit will run gravity fed only!
Media capacity is approximately 40 litres and can take micro K1.
An additional bolt on bio unit will be available, allowing the user to seamlessly double the biological capacity of the filter.
- The integrated controller has start / emergency stop buttons and a knob allowing you to change the length of wash. LED indicator shows the length of time between washes in minutes. Status of the unit is via 4 colour coded LEDs.
- Low voltage, sealed water valves and drive units utilising an extremely low geared stepper motor drive system mean that only 12 volts is anywhere near your pond water.
- Designed to run without a noisy and power hungry wash pump in most circumstances (they are available if required). On standby the unit can use less than 12 watts and in full wash mode, use 35 watts. It is entirely possible to run it off a car battery for prolonged periods of time.
Combi Unit
Dimensions (Including inlet/outlet pipes) – 350mm wide x 1215mm long x 488mm high
Height above water level – 175mm
Pond Volume – Approx 2,000 UK gallons
Single 3” inlet and outlets
recommend air pump size 40ltr
no media included
https://youtu.be/5MG-TJhXDbI
https://youtu.be/E5jc4C8a1U0
Draco Drum Magna Combi Unit
Draco Drum Magna Combi Unit
160mm (Height above water level gravity mode)
Flow rate – 50,000 LPH (gravity) @58µm
40,000 LPH (Pump fed) @58µm
Theoretical Pond Capacity – 8000 to 10000 Gallons (36,000 to 45,000 litres)
Inlets – 4 x 110mm
Outlets – 2 x 110mm plus 2” bio bypass connection
Bio capacity – Maximum 250 litres of media (Hel-x 13 recommended)
no media included
FEATURES
Sloped and slotted base to drum chamber, to eliminate bio media clogging and particle buildup in this area
Internal bio-bypass pipe for direct drum to shower connection. This is removable if not required
Large diameter and short length drum to maximise bio space and reduce water usage.
Extra deep waste tray with increased slope
Built in drum bypass plate
Hi-torque true brushless motor drive
All 12v dc operation at the drum
Plug and play design with single electrical connection
Modular component construction
Draco Drum Medius Combi unit
Draco Drum Medius Combi unit
The remotely sited controller has start / emergency stop buttons and a knob allowing you to change the length of wash. LED indicator shows the length of time between washes in minutes. It also has 2 leads – one to plug in to the mains supply (110v and 230v, auto selectable) and one to plug in to the drum. Status of the unit is via 4 colour coded LEDs. We didn’t think we could make it any simpler than that.
Low voltage, sealed water valves and drive units utilising an extremely low geared direct drive system mean that only 12 volts is anywhere near your pond water.
The Draco Drum Medius Combi unit was designed to run without a noisy and power hungry wash pump in most circumstances (they are available if required) . On standby the unit can use less than 1.2 watts and in full wash mode, use 35 watts. It is entirely possible to run it off a car battery for prolonged periods of time.
https://youtu.be/8LNjERrfnY8
Draco drum solum 16
Draco drum solum 16 Features
- Dimensions – 610mm wide x 570mm long x 581mm depth
- Height above water level – 180mm
- Capacity – 3,700 Imp gallons per hour / 16,800 litres per hour (in gravity mode, pump fed less 25%)
- Pond Volume – Approx 7,500 UK gallons
- Twin 4” inlet and outlets
- Easily removable Bypass plates
The engineering and understanding of how filtration works was developed to produce Draco drum solum 16. As with the ‘Drop-in’ Draco drum range these have some unique features to help eliminate deadspots that are usually found in standalones.
The Draco drum solum 16 are pretty enough for you not to want to hide them away.
The remotely sited controller has start / emergency stop buttons and a knob allowing you to change the length of wash. LED indicator shows the length of time between washes in minutes. It also has 2 leads – one to plug in to the mains supply (110v and 230v, auto selectable) and one to plug in to the drum. Status of the unit is via 4 colour coded LEDs. We didn’t think we could make it any simpler than that.
Low voltage, sealed water valves and drive units utilising an extremely low geared direct drive system mean that only 12 volts is anywhere near your pond water.
The Draco drum solum 16 was designed to run without a noisy and power hungry wash pump in most circumstances (they are available if required) . On standby the unit can use less than 12 watts and in full wash mode, use 35 watts. It is entirely possible to run it off a car battery for prolonged periods of time.
https://youtu.be/Tzi0gJNUnYg
Draco drum solum 25
Draco drum solum 25 Features
- Dimensions – 610mm wide x 700mm long x 581mm depth
- Height above water level – 180mm
- Capacity – 5,500 Imp. Gallons per hour / 25,000 litres per hour (in gravity mode, pump fed less 25%)
- Pond Volume – Approx 10,000 UK gallons
- Twin 4” inlet and outlets
- Easily removable Bypass plates
The engineering and understanding of how filtration works was developed to produce Draco drum solum 25. As with the ‘Drop-in’ Draco drum range these have some unique features to help eliminate deadspots that are usually found in standalones.
The Draco drum solum 25 are pretty enough for you not to want to hide them away.
The remotely sited controller has start / emergency stop buttons and a knob allowing you to change the length of wash. LED indicator shows the length of time between washes in minutes. It also has 2 leads – one to plug in to the mains supply (110v and 230v, auto selectable) and one to plug in to the drum. Status of the unit is via 4 colour coded LEDs. We didn’t think we could make it any simpler than that.
Low voltage, sealed water valves and drive units utilising an extremely low geared direct drive system mean that only 12 volts is anywhere near your pond water.
The Draco drum solum 25 was designed to run without a noisy and power hungry wash pump in most circumstances (they are available if required) . On standby the unit can use less than 12 watts and in full wash mode, use 35 watts. It is entirely possible to run it off a car battery for prolonged periods of time.
https://youtu.be/NrBHjMBxV-A
Draco drum solum 70
Draco drum solum 70
- Dimensions – 738mm wide x 677mm long x 848mm depth
- Height above water level – 153mm
- Capacity – 15,400 Imp. Gallons per hour / 70,000 litres per hour (in gravity mode, pump fed less 25%)
- Pond Volume – Approx 16,000 UK gallons
- 4 X 4” inlets and 3 x 4″ outlets with an extra 2″ out for direct pump (other layouts can be specified)
- Drum mounted bypass plate
- Heavy duty 70 µm screen
- The remotely sited controller has start / emergency stop buttons and a knob allowing you to change the length of wash. LED indicator shows the length of time between washes in minutes. It also has 2 leads – one to plug in to the mains supply (110v and 230v, auto selectable) and one to plug in to the drum. Status of the unit is via 4 colour coded LEDs. We didn’t think we could make it any simpler than that.
- Low voltage, sealed water valves and drive units utilising an extremely low geared direct drive system mean that only 12 volts is anywhere near your pond water.
- Designed to run without a noisy and power hungry wash pump in most circumstances (they are available if required) . On standby the unit can use less than 12 watts and in full wash mode, use 35 watts.
EconoBead Complete System
EconoBead Complete System
Unique to the UK market, a complete plug and play filter installation consisting of Econobead EB 50 or Econobead EB 60 with by pass, Midisieve, 40 watt power UV T5 and Forza 15000 pump.
EconoBead Complete System is installed on a polymer pallet. This only needs 3 connections to the pond system.
- Inlet from Bottom Drain
- Return to Pond
- Waste Outlet
Pallet size is 100 cm x 120 cm x 85 cm High.
Econobead EB 50 is suited for ponds up to 20000 ltrs (4400 gallons)
Econobead EB 60 is suited for ponds up to 30000 ltrs (6600 gallons)
The EconoBead Bead filters are the economical answer to imitation filters, made by the Beadfilter experts!
The EconoBead Beadfilters have a strong quality polypropylene vessel and are standard equipped with:
- A drain valve to remove the sludge from the bottom of the Econobead
- A 6 way valve
- A very reliable blower
- The blower is also equipped with a silencer.
The UltraSieve Midi is a Gravity Fed pre-filter to filter waste solids from the water via a bottom drain or through a skimmer. This technique is based upon the very successful Ultrasieve III, which incorporates a sieve-bend. A sieve-bend consists of hundreds of sharp stainless steel profile wires with very small slot openings where the water can go through but the solids stay on the sieve bend. In practice it works as follows:
The water enters the Ultrasieve Midi via the Ultraskim or bottom drain and passes through the “auto-adjustable” dam and will go upwards and fall over the weir on to the Stainless Steel sieve-bend.
Kockney Koi 10000V Fibreglass Filter
Kockney Koi 10000V Fibreglass Filter
The KF10000V is a high quality, free-standing, fibreglass, four bay, filter with integral vortex designed to improve your fish’s environment. Its “state-of-the art” multi chamber ensures maximum filtration with the minimum of maintenance. The unit is suitable for fish ponds of up to 10,000 litres and a maximum flow rate of 6,000 litres ph. However, with lighter stocking densities or in fish free ponds the KF10000 will comfortably cope with larger volumes. The integral Vortex enhances the unit’s performance and reduces the maintenance intervals
The media package consists of:
Specifications:
Bay 1: Six 16″ long x 8″ diametre polypropylene filter brushes – They are of a semi-rigid construction with a wire loop at the end for easy installation.
Bay 2: Blue matting – This is an excellent filter media as it has excellent bio-mass retention and its open texture removes larger particles from the water.
Bay 3: Six layers of sponge with varying layers of porosity, two large foam blocks and a layer of flocor.
Bay 4: Filled with Flocor. The large surface area of Flocor tubes makes it an ideal filter media.
81” long x 21” wide x 24” Deep
Maximum flow rate 6,000 litre per hour
Three drainage points – (Accepts 1.5″ solvent weld pipe for remote drainage)
Supplied with 3 1.5″ Kockney Koi Ball Valves
The pump fed model has a 4″ inlet and outlet while the gravity fed model has a 4″ inlet and 1.5″ outlet.
Both Options are supplied including media
Kockney Koi 18000V Fibreglass Filter
Kockney Koi 18000V Fibreglass Filter
The KF18,000V is a high quality, free-standing, fibreglass, four bay, filter with integral vortex designed to improve your fish’s environment. Its “state-of-the art” multi chamber design ensures maximum filtration with the minimum of maintenance. The unit is suitable for fish ponds of 18,000 litres and a maximum flow rate of 11,000 litres per hour. However, with lighter stocking densities or in fish free ponds the KF18,000 will comfortably cope with much larger volumes. The integral Vortex enhances the unit’s performance and reduces the maintenance intervals
Specifications:
The media package consists of:
Bay 1: Eighteen 16″ long x 8″ diametre polypropylene filter brushes – They are of a semi-rigid construction with a wire loop at the end for easy cleaning.
Bay 2: Blue matting – This is an excellent filter media as it has a large surface area giving it an excellent bio-mass retention. Its open texture removes larger particles from the water.
Bay 3: Three layers of reticulated foam with different density of porosity of each layer. This is on top of a layer of approximately 2 cubic foot of flocor.
Bay 4: Six way foam block manifold assembly on top of six cubic foot of Flocor. The large surface area of Flocor tubes makes it an ideal filter media.
102 ” long x 33” wide x 32” Deep
Maximum flow rate 11,000 litre per hour
Three drainage points – (Accepts 1.5″ solvent weld pipe for remote drainage)
Supplied with 3 x 1.5″ Kockney Koi Ball Valves (Not shown)
The gravity fed model has a 4″ inlet and 1.5″ outlet where the pump fed model has a 1.5″ inlet and 4″ outlet.
Both Options are supplied including media
Kockney Koi 5000V Fibreglass Filter
Kockney Koi 5000V Fibreglass Filter
The KF 5000V is a high quality, free-standing, fibreglass, four bay, filter with integral vortex designed to improve your fish’s environment. Its “state-of-the art” multi chamber ensures maximum filtration with the minimum of maintenance. The unit is suitable for fish ponds of up to 5000 litres and a maximum flow rate of 3000 litres ph. However, with lighter stocking densities or in fish free ponds the KF4000 will comfortably cope with larger volumes. Complete with a new media package consisting of: filter brushes, Japanese matting, wadding and flocor. The integral Vortex enhances the unit’s performance and reduces the maintenance intervals. It is suitable for Pump or Gravity feed. Fitted with 3″ inlet and 2″ outlet. Pump fed version comes complete with 2 x 2″ outlets.
Specifications:
5000V (4 Bay) 51” x 17” x 19” Deep
Maximum flow rate 3,000 litre per hour
Inlet size 3” – Outlet 2” solvent (pump fed 2 x 2″ outlets)
Three drainage points – (Accepts 1.5″ solvent weld pipe for remote drainage)
Media: flocor, matting cartridge, brushes, and filter wadding
Both Options are supplied including media
Kockney koi 8000 Fibreglass Filter
Kockney koi 8000 Fibreglass Filter
The KF8000 is available as pump fed (KF8000P) and gravity fed (KF8000G). It is a high quality, free-standing, fibreglass, three bay, filter designed to improve your fish’s environment. Its “state-of-the art” multi chamber ensures maximum filtration with the minimum of maintenance. The unit is suitable for fish ponds of up to 8000 litres and a maximum flow rate of 6000 litres ph. However, with lighter stocking densities or in fish free ponds the KF8000 will comfortably cope with much larger volumes. Complete with multi spray bar (pump fed), filter brushes, Japanese matting and flocor. Its clever design enables it to fit through a standard 30″ domestic door opening (if required) so it can be transported through the house for those properties where there is no side or rear access. Optional matching vortex (VF1) available for gravity fed model (KF8000G).
Specifications:
8000 Litre (3 Bay) 37″ x 31.5″ x 24.5″ Deep
Maximum flow rate 6,000 litre per hour
Pump fed – Inlet size 1.5” – Outlet 110mm solvent
Gravity fed – inlet size 110mm – outlet 1.5”
Available as gravity or pump fed complete with: 2 drains and 2 Ball Valves
Media: flocor, blue matting cartridge and brushes
Both Options are supplied including media
Kockney Koi Filter 4000
Kockney Koi Filter 4000
The 4000FG is a Pump Fed, high quality, free-standing, fibreglass, four bay, filter designed to improve your fish’s environment. Its “state-of-the art” multi chamber ensures maximum filtration with the minimum of maintenance. The unit is suitable for ponds of up to 4000 litres and a maximum flow rate of 3000 litres ph.
However, with lighter stocking densities the KF 4000 will comfortably cope with larger volumes. 1.5” inlet & 2” Outlet. Complete with multi spray bar, filter brushes, Japanese matting and flocor.
Specifications:
4000 Litre (4 Bay) 36” x 17” x 19” Deep
Maximum flow rate 3,000 litre per hour
Inlet size 1.5” – Outlet 2” solvent
Available pump fed with spray bar complete with or without media
Two drainage points – (Accepts 1.5″ solvent weld pipe for remote drainage)
Media: flocor, matting cartridge, brushes, filter wadding
Supplied including media
Nexus 220+ Filter
The Nexus 220+
Evolution Aqua have launched the Nexus320+ and Nexus220+ filtration systems. Building on the tried and tested technology that has been ever present in the world renowned Nexus, the team at Evolution Aqua have gone even further to enhance their number one Koi pond filter.
The Nexus320+ and Nexus220+ filters now come with a new filter media called K+ Media in the moving bed outer chamber for vastly improved biological filtration and faster filter maturation. The new Nexus+ filters are also supplied “auto ready”, with factory fitted fixings already in place, making it even easier to upgrade to the Nexus Automatic Cleaning System.
Technical Data:
- Maximum pond size: 18,000 litres / 4,000 gallons
- Recommended flow rate: 6,000 litres per hour
- Maximum flow rate: 10,000 litres per hour
- Volume of water in Nexus: 510 litres
- Amount of K1 Micro in EAZY: 18 litres
- Amount of K+Media supplied: 50 litres
- Maximum amount of K+Media: 150 litres
Nexus 220 Filter Lid
The Nexus 220 Filter Lid
The Nexus 220 Filter Lid is vey light weight and very durable and UV resistant. They fit perfectly on top of the Nexus Eazy 220 & Nexus Eazy 320 systems.
The lids are very well made, robust and of course will with-stand the outside weather conditions as well, but more importantly it will keep out light as well as debris which will effect the Bio mass inside the Nexus Eazy 220 Filters.
Simply a must when buying the Nexus Eazy 220 or Nexus Eazy 320 filters.
Nexus 320+ Filter
The Nexus 320+
Evolution Aqua have launched the Nexus320+ and Nexus220+ filtration systems. Building on the tried and tested technology that has been ever present in the world renowned Nexus, the team at Evolution Aqua have gone even further to enhance their number one Koi pond filter.
The Nexus320+ and Nexus220+ filters now come with a new filter media called K+ Media in the moving bed outer chamber for vastly improved biological filtration and faster filter maturation. The new Nexus+ filters are also supplied “auto ready”, with factory fitted fixings already in place, making it even easier to upgrade to the Nexus Automatic Cleaning System.
Technical Data:
- Maximum pond size: 34,000 litres / 7,500 gallons
- Recommended flow rate:11,000 litres per hour
- Maximum flow rate:13,000 litres per hour
- Volume of water in Nexus:840 litres
- Amount of K1 Micro in EAZY:20 litres
- Amount of K+Media supplied:100 litres
- Maximum amount of K+Media:300 litres
Nexus 320 Filter Lid
The Nexus 320 Filter Lid
The Nexus 320 Filter Lid is vey light weight and very durable and UV resistant. They fit perfectly on top of the Nexus Eazy 220 & Nexus Eazy 320 systems.
The lids are very well made, robust and of course will with-stand the outside weather conditions as well, but more importantly it will keep out light as well as debris which will effect the Bio mass inside the Nexus Eazy 220 Filters.
Simply a must when buying the Nexus Eazy 220 or Nexus Eazy 320 filters.
Eazy Pod Grey
Eazy Pod Grey
Easy to use filter system
A compact member of the Nexus family, the Eazy Pod is a mechanical and biological filter system for ponds up to 10,000 litres.
The Eazy Pod utilises 18 litres of static K1 Micro, which provides enhanced biological benefits, even when using the Eazy Pod solely as a mechanical waste filter.
Available in Grey or Granite Green colours.
Overview
A compact member of the Nexus family, the Eazy Pod is a mechanical and biological filter system for ponds up to 10,000 litres. The Eazy Pod utilises 18 litres of static K1 Micro, which provides enhanced biological benefits, even when using the Eazy Pod solely as a mechanical waste filter. Also available as Eazy Pod Air models, which come supplied with AirPump70 Kit.
- Max Pond Size: 20,000 Litres
- Max Koi Pond Size: 10,000 Litres
- Maximum garden pond flow rate: 10,000 lph
- Maximum Koi Pond flow rate: 5,000 lph
- Kaldnes K1 Micro media: 18 litres included
- Recommended Air Pump: 70 litres
Eazy Pod Air Green
The Eazy Pod Air Green
The Eazy Pod Air Green, best small pond filter just got better ! Due to popular demand the Eazy Pod is now also available with an Airtech 70 Air Pump kit.
Introducing the Eazy Pod Air Green, yes thats right the kit includes a Airtech 70 Air Pump, manifold, 10m airline & 2 air stones.
The Eazy pod Air Green for smaller ponds has unparalleled results, the Eazy Pod Air is the latest to come from the Evolution Aqua stable and is set to meet the challenge of today’s koi Pond enthusiast.
The Eazy pod Air Features:
- is a complete filter and air Pump system for smaller ponds with unparalleled results
- comes complete with Airtech 70 Air Pump, manifold, 10m airline & 2 air stones
- is a small filter (only 23 inches tall) utilising proven Nexus Eazy success
- has a Quick and eazy cleaning cycle with the supplied Airtech 70 Air Pump
- With their is no wet or dirty hands
- comes complete with adjustable rubber connectors (all pipework up to 3 inch)
- works equally well pump or gravity fed
- also comes with a compact lid as standard.
- Max Pond Size: 20,000 Litres
- Max Koi Pond Size 10,000 Litres
- Maximum garden pond flow rate: 10,000 lph
- Maximum Koi Pond flow rate: 5,000 lph
- Kaldnes K1 media: 25 litres included
- Recommended Air Pump: 40 litres
Eazy Pod Air Grey
The Eazy Pod Air Grey
The Eazy Pod Air Grey, best small pond filter just got better ! Due to popular demand the Eazy Pod is now also available with an Airtech 70 Air Pump kit.
Introducing the Eazy Pod Air Grey, yes thats right the kit includes a Airtech 70 Air Pump, manifold, 10m airline & 2 air stones.
The Eazy pod Air Green for smaller ponds has unparalleled results, the Eazy Pod Air is the latest to come from the Evolution Aqua stable and is set to meet the challenge of today’s koi Pond enthusiast.
The Eazy pod Air Features:
- is a complete filter and air Pump system for smaller ponds with unparalleled results
- comes complete with Airtech 70 Air Pump, manifold, 10m airline & 2 air stones
- is a small filter (only 23 inches tall) utilising proven Nexus Eazy success
- has a Quick and eazy cleaning cycle with the supplied Airtech 70 Air Pump
- With their is no wet or dirty hands
- comes complete with adjustable rubber connectors (all pipework up to 3 inch)
- works equally well pump or gravity fed
- also comes with a compact lid as standard.
- Max Pond Size: 20,000 Litres
- Max Koi Pond Size 10,000 Litres
- Maximum garden pond flow rate: 10,000 lph
- Maximum Koi Pond flow rate: 5,000 lph
- Kaldnes K1 media: 25 litres included
- Recommended Air Pump: 40 litres
Eazy Pod Filter Kit for koi pond (set)
Eazy Pod Filter Kit for koi pond
At Cotswold koi We understand that sometimes it can be confusing as to knowing what equipment you require for your pond, So we have put together this kit which will make your life a 100% easier. This Eazy Pod filter kit is recommended for koi ponds 1000-1500 uk gallons or up to 2200 uk gallons on lightly stocked ponds.
Eazy Pod Air Grey
The Eazy Pod Air Grey, best small pond filter just got better ! Due to popular demand the Eazy Pod is now also available with an Airtech 70 Air Pump kit.
Introducing the Eazy Pod Air Grey, yes that’s right the kit includes a Airtech 70 Air Pump, manifold, 10m airline & 2 air stones.
The Eazy pod Air Greyfor smaller ponds has unparalleled results, the Eazy Pod Air is the latest to come from the Evolution Aqua stable and is set to meet the challenge of today’s koi Pond enthusiast.
The Eazy pod Air Features:
- is a complete filter and air Pump system for smaller ponds with unparalleled results
- comes complete with Airtech 70 Air Pump, manifold, 10m airline & 2 air stones
- is a small filter (only 23 inches tall) utilising proven Nexus Eazy success
- has a Quick and eazy cleaning cycle with the supplied Airtech 70 Air Pump
- With their is no wet or dirty hands
- comes complete with adjustable rubber connectors (all pipework up to 3 inch)
- works equally well pump or gravity fed
- also comes with a compact lid as standard.
This is a set kit to customise click here
Contct us if you require help build a kit for your protect
Eazy Pod Complete Green
The Eazy Pod Complete Green
The Eazy Pod Complete Green (complete with 18 watt Uv) Eazy, best small pond filter just got better ! Due to popular demand the Eazy Pod Air Uv Complete is now also available with an Airtech 70 Air Pump kit and built in 18 watt Uv.
Introducing the Eazy Pod Complete Green, yes thats right the kit includes a Airtech 70 Air Pump, manifold, 10m airline & 2 air stones and a built in 18 watt UV
Eazy Pod Complete Green for smaller ponds has unparalleled results, the Eazy Pod Air UV Complete is the latest to come from the Evolution Aqua stable and is set to meet the challenge of today’s koi Pond enthusiast.
Eazy Pod Complete Green with 18 Watt UV Features:
- Complete is a complete filter and air Pump system for smaller ponds with unparalleled results
- Complete comes complete with Airtech 70 Air Pump, manifold, 10m airline & 2 air stones and 18 watt UV
- Complete is a small filter (only 23 inches tall) utilising proven Nexus Eazy success
- Complete has a Quick and eazy cleaning cycle with the supplied Airtech 70 Air Pump
- With the Eazy Pod their is no wet or dirty hands
- comes complete with adjustable rubber connectors (all pipework up to 3 inch)
- Complete for pump fed applications only
- Complete also comes with a compact lid as standard.
- Max Pond Size: 20,000 Litres
- Max Koi Pond Size 10,000 Litres
- Maximum garden pond flow rate: 10,000 lph
- Maximum Koi Pond flow rate: 5,000 lph
- Kaldnes K1 media: 25 litres included
- Recommended Air Pump: Airtech 40 litres
Eazy Pod Complete Grey
Eazy Pod Complete Grey
The Eazy Pod Complete Grey (complete with 18 watt Uv) Eazy, best small pond filter just got better ! Due to popular demand the Eazy Pod Air Uv Complete is now also available with an Airtech 70 Air Pump kit and built in 18 watt Uv.
Introducing the Eazy Pod Complete Grey, yes that’s right the kit includes a Airtech 70 Air Pump, manifold, 10m airline & 2 air stones and a built in 18 watt UV
TheEazy Pod Complete Grey for smaller ponds has unparalleled results, the Eazy Pod Air UV Complete is the latest to come from the Evolution Aqua stable and is set to meet the challenge of today’s koi Pond enthusiast.
The Eazy Pod Air UV Complete with 18 Watt UV Features:
- Complete is a complete filter and air Pump system for smaller ponds with unparalleled results
- Complete comes complete with Airtech 70 Air Pump, manifold, 10m airline & 2 air stones and 18 watt UV
- Complete is a small filter (only 23 inches tall) utilising proven Nexus Eazy success
- Complete has a Quick and eazy cleaning cycle with the supplied Airtech 70 Air Pump
- With the Eazy Pod their is no wet or dirty hands
- comes complete with adjustable rubber connectors (all pipework up to 3 inch)
- Complete for pump fed applications only!!!!!!!
- Complete also comes with a compact lid as standard.
- Max Pond Size: 20,000 Litres
- Max Koi Pond Size 10,000 Litres
- Maximum garden pond flow rate: 10,000 lph
- Maximum Koi Pond flow rate: 5,000 lph
- Kaldnes K1 media: 25 litres included
- Recommended Air Pump: Airtech 40 litres
Eazy Pod Green
Eazy Pod Green
Easy to use filter system
A compact member of the Nexus family, the Eazy Pod is a mechanical and biological filter system for ponds up to 10,000 litres.
The Eazy Pod utilises 18 litres of static K1 Micro, which provides enhanced biological benefits, even when using the Eazy Pod solely as a mechanical waste filter.
Available in Grey or Granite Green colours.
Overview
A compact member of the Nexus family, the Eazy Pod is a mechanical and biological filter system for ponds up to 10,000 litres. The Eazy Pod utilises 18 litres of static K1 Micro, which provides enhanced biological benefits, even when using the Eazy Pod solely as a mechanical waste filter. Also available as Eazy Pod Air models, which come supplied with AirPump70 Kit.
- Max Pond Size: 20,000 Litres
- Max Koi Pond Size: 10,000 Litres
- Maximum garden pond flow rate: 10,000 lph
- Maximum Koi Pond flow rate: 5,000 lph
- Kaldnes K1 Micro media: 18 litres included
- Recommended Air Pump: 70 litres
Filtreau Drum filter
Filtreau Drum filter
Now look what we have here!. A drum filter for the price of a good quality sieve. If that was not enough, these Filtreau Drum filters come complete with a built in 40watt Amalagam UV as well. There is no other prefilter available on the market that represents such a good price.
These Filtreau Drum filters have been produced to provide an entry level into the drum filter market. But the quality of these drum filters are superb for the price and represent excellent value for money.
Designed for ponds up to 5000 gallons these Filtreau Drum filters have two 4″ (110mm) inlets and one 110mm outlet for connection of the circulation pump, and one 4″ (110mm) outlet for the waste.
The drum filter comes complete with all the control gear and as mentioned above also has a 40watt Amalagam UV built in.
This drum filter, with it’s 60 micron screen will filter particles out of the ponds water automatically with the automatic cleaning process that is built into the drum. Sensors monoitor the water levels within the drum filter and a cleaning cycle is activated as and when necessary to ensure that all waste particles are removed and then flushed to waste.
There are two options available for this backwash process, you can either connect the drum up to the mains water supply and use mains water to clean the drum (a solenoid valve will be required for this option which we can supply), or a optional pressure pump can be purchased which wll be controlled by the drums built in controller and use the water held within the drum to clean the drum’s screen.
The motor that rotates the drum and the control gear have been used on other drum filters in the Netherlands and fully tested over the past 3 years so you can buy with confidence both on quality and reliablity.
The manufacturer of this Filtreau Drum filter will be shortly releasing an add on Bio-Chamber that will connect to this drum filter to provide all the biological filtration required for your pond. We will update this section as soon as they are available. This option will then enable you to have the full benefits of a Bio-Compact system which are the most cost effective and environmentally friendly forms of pond filtration available as lower wattage pumps can be used on the circulation of your ponds water.
Filtreau Moving Bed Bio Chamber
Filtreau Moving Bed Bio Chamber
The Filtreau moving-bed is a bio filtration system with a 190L bio-chamber wich ensures crystal-clear water. The moving-bed is suitable for (koi) ponds up to as much as 30.000L!
Inlets and outlets require Fitting prior to install.
Dimensions:
57 x 57 x 78 cm (L x W x H)
Draco 2 Drum
Draco 2 Drum
The Draco 2 Drum is a reasonably priced and reliable unit. It comes with a choice of screens 77 microns and 58 microns depending on what is required. This Drum Can be used without a pressure wash pump – wash cycle runs off a normal garden hose with a minimum pressure of 2.5 bar with good flow. The Origin uses 28 watts of power while active, 11.5 watts while on standby and 78 watts while active with optional pressure pump. The Drive system comprises direct gearing to the back of the drum minimising complexity, the sealed motor unit is mounted on a single pivot swing arm as a safety feature to stop foreign bodies jamming the system. Its a fairly Simple installation via multiple types of adaptor plate which are interchangeable Single, pre-wired connection from controller to drum. Just plug and play ability to site controller up to 4 metres away from the unit. The Status of controller is available via simple, high intensity, colour coded LEDs and a digital minute between washes display. Easily accessible water level sensors that can be adjusted to accommodate any situation
All parts are modular and are replaceable in the event of any damage or failure Wholly designed and built in the UK by Draco Drum.
Technical Data:
- 2450gph / 13000lph flow rate
- Single 90mm inlet
- Filters to 58 micron
- Gravity or pump fed
- Designed to wash from mains pressure (down to 2 bar)
- 11 watts standby / 28 watts wash
- 12 volts DC waterside electrics
- Simple plug and play design
- Polypropolene / stainless steel construction
- Totally modular – all parts user replaceable
- Optional bolt on wash pump (for low water pressure areas)
Evolve mini shower- Bacteria Shower
The Evolve mini Bacteria Shower another great addition to the evolve range.
Overall dimensions are; 540mm long x 250mm wide x 780mm tall.
Supplied with a 2-inch removable spray bar should the user wish to drill more holes.
Extra tiers can be purchased separately should a larger capacity shower be required.
The Bacteria Shower comes with the standard waterfall type base to sit on the pond wall but can be ordered with a piped base if required to allow the outflow to be piped to a certain location.
A two-spray bar top tier of the shower is available if extra water volume is required.
This shower has a recommended maximum flow rate of 4,000 gallons per hour (18,000 litres).
