Kockney Koi Filter 4000

Kockney Koi 8000 Fibreglass Filter

The KF8000 is available as pump fed (KF8000P) and gravity fed (KF8000G). It is a high quality, free-standing, fibreglass, three bay, filter designed to improve your fish’s environment. Its “state-of-the art” multi chamber ensures maximum filtration with the minimum of maintenance. The unit is suitable for fish ponds of up to 8000 litres and a maximum flow rate of 6000 litres ph. However, with lighter stocking densities or in fish free ponds the KF8000 will comfortably cope with much larger volumes. Complete with multi spray bar (pump fed), filter brushes, Japanese matting and flocor. Its clever design enables it to fit through a standard 30″ domestic door opening (if required) so it can be transported through the house for those properties where there is no side or rear access. Optional matching vortex (VF1) available for gravity fed model (KF8000G). Read more

Specifications:

• 8000 Litre (3 Bay) 37″ x 31.5″ x 24.5″ Deep
• Maximum flow rate 6,000 litre per hour
• Pump fed – Inlet size 1.5” – Outlet 110mm solvent
• Gravity fed – inlet size 110mm – outlet 1.5”
• Available as gravity or pump fed complete with: 2 drains and 2 Ball Valves
• Media: flocor, blue matting cartridge and brushes

Both Options are supplied including media

Kockney Koi 5000V Fibreglass Filter

The KF 5000V is a high quality, free-standing, fibreglass, four bay, filter with integral vortex designed to improve your fish’s environment. Its “state-of-the art” multi chamber ensures maximum filtration with the minimum of maintenance. The unit is suitable for fish ponds of up to 5000 litres and a maximum flow rate of 3000 litres ph. However, with lighter stocking densities or in fish free ponds the KF4000 will comfortably cope with larger volumes. Complete with a new media package consisting of: filter brushes, Japanese matting, wadding and flocor. The integral Vortex enhances the unit’s performance and reduces the maintenance intervals. It is suitable for Pump or Gravity feed. Fitted with 3″ inlet and 2″ outlet. Pump fed version comes complete with 2 x 2″ outlets. Read more

Specifications:

• 5000V (4 Bay) 51” x 17” x 19” Deep
• Maximum flow rate 3,000 litre per hour
• Inlet size 3” – Outlet 2” solvent (pump fed 2 x 2″ outlets)
• Three drainage points – (Accepts 1.5″ solvent weld pipe for remote drainage)
• Media: flocor, matting cartridge, brushes, and filter wadding

Both Options are supplied including media

Kockney Koi 18000V Fibreglass Filter

The KF18,000V is a high quality, free-standing, fibreglass, four bay, filter with integral vortex designed to improve your fish’s environment. Its “state-of-the art” multi chamber design ensures maximum filtration with the minimum of maintenance. The unit is suitable for fish ponds of 18,000 litres and a maximum flow rate of 11,000 litres per hour. However, with lighter stocking densities or in fish free ponds the KF18,000 will comfortably cope with much larger volumes. The integral Vortex enhances the unit’s performance and reduces the maintenance intervals.

Features:

• 102 ” long x 33” wide x 32” Deep
• Maximum flow rate 11,000 litre per hour
• Three drainage points – (Accepts 1.5″ solvent weld pipe for remote drainage)
• Supplied with 3x 1.5″ Kockney Koi Ball Valves (Not shown)
• The gravity fed model has a 4″ inlet and 1.5″ outlet where the pump fed model has a 1.5″ inlet and 4″ outlet.

Both Options are supplied including media
